Unknown Unknown (2008 - 2009)

The Buell Ulysses embodies the essence of adventure and performance, blending the thrill of off-pavement exploration with the precision handling of a high-performance motorcycle.

Its premium Showa suspension is fully adjustable, allowing riders to tailor settings to suit their needs. The innovative Triple Tail system offers versatility, transforming into a luggage rack, passenger backrest, or storage compartment with ease.

The 103-hp Buell Firestorm engine delivers broad power and abundant torque, making it an ideal companion for navigating twisty pavement sections or tackling uneven terrain at lower speeds.

Key Specifications

Engine Type	45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Engine Capacity	1203 cc / 73 cu in
Max Power	86.9 kw / 103 hp
Max Torque	114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm
Fuel Tank Capacity	16.7 L / 4.4 US gal
Seat Height	841 mm / 33.1″

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Unknown Unknown
Year	2008 – 2009

Engine

Engine Type	45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Displacement	1203 cc / 73 cu in
Bore x Stroke	88.9 x 96.8 mm
Compression Ratio	10.0:1
Max Horsepower	86.9 kw / 103 hp
Max Torque	114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm
Engine Management System	49 mm downdraft DDFI II fuel injection
Lubrication System	Dry sump
Cooling System	Air cooled
Exhaust	Buell InterActive Exhaust

Performance

Top Speed

202 km/h / 126 mph

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet, multi-plate
Gearbox	5 Speed
Gear Ratios	1st2.648 / 2nd1.892 / 3rd1.407 / 4th1.166 / 5th1.000
Final Drive	Belt

Electrical & Electronics System

Battery	12V, 12Ah
Starter	Electric

Chassis & Suspension

Frame Type	Aluminium frame with Uniplanar Powertrain vibration isolation system, fuel in frame
Front Suspension	Showa 43 mm inverted forks compression damping, rebound damping and spring preload adjustable
Front Suspension Travel	165 mm / 6.5″
Rear Suspension	Showa coil-over monoshock, remote underseat reservoir and adjustable compression damping, rebound damping and spring preload
Rear Suspension Travel	163 mm / 6.4″
Rake	22
Trail	122 mm / 4.8″

Wheels & Brakes

Wheels	6-Spoke, ZTL cast aluminium
Front Wheel/Rim Size	3.50 x 17″
Front Tire Size	120/70 R17 Dunlop D616F
Rear Wheel/Rim Size	5.50 x 17″
Rear Tire Size	180/55 R17 Dunlop D616
Front Brakes	ZTL type brake, 6 piston, fixed caliper, 375 mm single-sided, inside out, stainless steel, floating rotor
Rear Brakes	Single 240 mm disc, 1 piston floating caliper

Dimension & Weights

Overall Length	2159
Seat Height	841 mm / 33.1″
Wheelbase	1372 mm / 54.0″
Ground Clearance	171 mm / 6.75″
Fuel Tank Capacity	16.7 L / 4.4 US gal
Dry Weight	193 kg / 425 lbs

Features

Premium Showa front and rear suspension
Fully adjustable rear spring preload
Rear spring preload adjustment dial located below left side of seat
Suspension travel: 6.5 inches front, 6.4 inches rear
Ground clearance: 6.75 inches
Lower center of mass due to frame-mounted fuel tank and swing arm-mounted oil reservoir
Limited unsprung weight for improved control
17-inch, six-spoke, reinforced cast-aluminum wheels
Dual front fender system for debris protection
High, wide handlebar with cross brace, deflectors, and two-piece windscreen
Triple Tail luggage rack system with three positions (luggage rack, passenger backrest, or extended luggage rack)
Two 10 amp/12-volt accessory power outlets
Large under-seat storage compartment
103-hp Buell Firestorm 1203 V-Twin engine
Broad powerband and abundant torque for on-road and off-road riding
New 47mm front forks with improved torsional rigidity and reduced fork flex during hard braking
Increased steering sweep lock-to-lock: 74 degrees (from 54 degrees)
Off-set triple clamps with 23.5 degree rake and 4.8 inch trail
Heated hand grips as standard equipment (18 watts per side on High, 11 watts per side on Low)

*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
