The Buell Ulysses XB12XT is a thrilling adventure sportbike that embodies the perfect blend of comfort and performance.
Billed as the second model in the Ulysses family, this capable long-distance motorcycle boasts intuitive handling and tremendous torque, making it an exhilarating ride on both twisty roads and open highways.
The XB12XT features a specially-tuned shorter travel suspension, lower standard seat height, and Pirelli Strada sport touring tires for exceptional grip and stability. The tall windscreen provides ample protection from the elements, while heated hand-grips keep riders’ hands warm in colder climates.
With its commanding riding position, abundant storage space, and convenient features like lockable top and side luggage cases, the XB12XT is poised to deliver an unforgettable riding experience that’s equally suited for zipping through city streets or exploring the great outdoors.
Key Specifications
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Engine Capacity
1203 cc / 73 cu in
Max Power
86.9 kw / 103 hp
Max Torque
114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6500 rpm
Fuel Tank Capacity
16.7 L / 4.4 US gal
Seat Height
780 mm / 30.7″
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Unknown Unknown
Year
2008 – 2009
Engine
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Displacement
1203 cc / 73 cu in
Bore x Stroke
88.9 x 96.8 mm
Compression Ratio
10.0:1
Max Horsepower
86.9 kw / 103 hp
Max Torque
114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6500 rpm
Engine Management System
DDFI 3 Electronic Fuel Injection ECM
Lubrication System
Dry sump
Cooling System
Air cooled
Exhaust
Buell InterActive Exhaust
Performance
Top Speed
206 km/h / 127.9 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate, compensated
Gearbox
5 Speed
Gear Ratios
1st2.68 / 2nd1.89 / 3rd1.407 / 4th1.14 / 5th1.000
Final Drive
Belt
Electrical & Electronics System
Battery
12V, 12Ah
Starter
Electric
Chassis & Suspension
Frame Type
Aluminium frame with Uniplanar Powertrain vibration isolation system, fuel in frame
Front Suspension
Showa 43 mm inverted forks compression damping, rebound damping and spring preload adjustable
Front Suspension Travel
124 mm / 4.9″
Rear Suspension
Showa coil-over monoshock, remote underseat reservoir and adjustable compression damping, rebound damping and spring preload
Rear Suspension Travel
124 mm / 4.9″
Rake
23.8
Trail
122 mm / 4.8″
Wheels & Brakes
Wheels
6-Spoke, ZTL cast aluminium
Front Wheel/Rim Size
3.50 x 17″
Front Tire Size
120/70 R17 Pirelli Strada
Rear Wheel/Rim Size
5.50 x 17″
Rear Tire Size
180/55 R17 Pirelli Strada
Front Brakes
ZTL type brake, 6 piston, fixed caliper, 375 mm single-sided, inside out, stainless steel, floating rotor
Rear Brakes
Single 240 mm disc, 1 piston floating caliper
Dimension & Weights
Overall Length
2180
Overall Width
1006 mm /
Seat Height
780 mm / 30.7″
Wheelbase
1369 mm / 53.9″
Ground Clearance
150 mm / 5.9″
Fuel Tank Capacity
16.7 L / 4.4 US gal
Dry Weight
211 kg / 465 lbs
Features
Shorter travel suspension
Lower standard seat height
Standard tall windscreen
Pirelli Strada sport touring tires
Standard lockable top box
Standard side luggage cases
Heated hand-grips
10 amp/12-volt accessory power outlets (2)
Integrated helmet lock
Lockable and detachable side and top luggage cases
Additional storage compartment under the seat
4.4 gallon fuel-in-frame reservoir
Comfortable passenger seat
Multi-function Triple tail backrest
Sturdy grab rails
Fully adjustable Showa suspension front and rear
43 mm inverted front forks
Remote reservoir and dial adjust spring preload on rear shock
