Key Specifications Engine Type Air-cooled SOHC 4-stroke single; 2 valves Engine Capacity 249 cc / 15.2 cubic inches Max Power n/a Max Torque n/a Top Speed ~ 74.5 mph / 120 kmph Fuel Tank Capacity 9.46 L / 2.5 US gallons Weight (Wet/Kerb) 132 kg / 291 lbs Seat Height 830.5 mm / 32.7 inches
*n/a – information not provided by manufacturer
All Specifications Make & Model Model Yamaha XT250 Year 2024
Engine Engine Type Air-cooled SOHC 4-stroke single; 2 valves Displacement 249 cc / 15.2 cubic inches Bore x Stroke 74 x 58 mm Compression Ratio 9.5 : 1 Number of Cylinders 1 Max Horsepower n/a Max Torque n/a Valve Train SOHC Valves per Cylinder 2 Engine Management System Yamaha Fuel Injection (YFI) Cooling System Air Cooled Ignition System TCI
Performance Fuel Consumption 32.3 kmpl / 76 mpg
*n/a – information not provided by manufacturer
Transmission Clutch Wet multiplate clutch Gearbox 5-speed Final Drive Chain
Electrical & Electronics System Headlight Type Halogen Instrumentation Multifunction digital LCD instrument
Chassis & Suspension Front Suspension 35mm telescopic fork Front Suspension Travel 226 mm / 8.9 inches Rear Suspension Single shock, adjustable preload Rear Suspension Travel 180 mm / 7.1 inches Rake 26.4 ° Trail 107 mm / 4.2 inches
Wheels & Brakes Wheels Wire aluminum wheels Front Tire Size 2.75-21 Rear Tire Size 120/80-18 Front Brakes Single disc, 245mm Rear Brakes Single disc, 203mm
Dimension & Weights Overall Length 2149 mm / 84.6 inches Overall Width 805 mm / 31.7 inches Overall Height 1161 mm / 45.7 inches Seat Height 830.5 mm / 32.7 inches Wheelbase 1359 mm / 53.5 inches Ground Clearance 284.4 mm / 11.2 inches Fuel Tank Capacity 9.46 L / 2.5 US gallons Wet (kerb/curb) Weight 132 kg / 291 lbs
Features Advanced Long-Travel Suspension Convenient Electric Start Front & Rear Disc Brakes Modern Fuel Injection Advanced LCD Instruments Bright Illumination Comfortable Saddle Dual Sport Lighting Extended Fuel Range Forest-Friendly Exhaust Fork Protection Modern Battery Passenger-Ready Protective Fenders Dirt-Ready Wheels Generous Ground Clearance Linkage-Style Shock Nimble Steering Strong, Compact Frame Advanced Cylinder Design Efficient Intake Design Five-Speed Transmission Low Maintenance Engine Reliable Four-Stroke Motor Responsive Power Trail-Ready Chassis Yamaha XT250 (2024) Color Options *We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
