The All-New 2025 Triumph TF 450-RC Edition: introducing an all-new 450cc competition engine, and the strongest power-to-weight ratio in its class. Developed in close collaboration with motocross legend Ricky Carmichael, it features RC’s handpicked specs and signature components, built to deliver relentless performance and ultimate control.
Key Specifications Engine Type 1-cylinder, 4-stroke DOHC Engine Capacity 449.5 cc Max Power 61.5 hp Max Torque n/a Top Speed n/a Fuel Tank Capacity 7 L / 1.85 US gallons Weight (Wet/Kerb) 108.6 kg / 239.42 lbs Seat Height 960 mm / 37.8 inches
*n/a – information not provided by manufacturer
All Specifications Make & Model Model Triumph TF 450-RC Year 2025 –
Engine Engine Type 1-cylinder, 4-stroke DOHC Displacement 449.5 cc Bore x Stroke 95 mm x 63.4 mm Compression Ratio 13.1 : 1 Number of Cylinders 1 Max Horsepower 61.5 hp Max Torque n/a Valve Train DOHC Valves per Cylinder 4 Engine Management System Dellorto Throttle Body, Athena EMS Lubrication System Pressure lubrication, with two trochoidal pumps Ignition System Fully electronic ignition Exhaust System Single Silencer
Performance *n/a – information not provided by manufacturer
Transmission Clutch Steel Wet Multi-Plate Belleville Spring, Hydraulic Actuation Gearbox 5 Speed Primary Drive Ratio 75:32 Gear Ratios 1st gear – 30:14 Final Drive Chain DID 520DMA4K SDH, 114 link non-O-ring Quick Shifter Yes. Only upshift from 2nd to 5th gear Traction Control System Yes
Electrical & Electronics System Battery HJTZ5S-FP Alternator/Generator 5 Amp at 2,000 rpm. 6 Amp at 8,000 rpm Headlight Type LED Taillight Type LED Instrumentation Hour Meter, Multifunction Switch Cubes Riding Modes 2 Engine Maps Traction Control System Traction Control Launch Control Yes
Chassis & Suspension Frame Type Aluminium, Spine Front Suspension KYB 48mm Coil Spring Fork, Compression/Rebound Adjustment Front Suspension Travel 310 mm / 12.2 inches Rear Suspension KYB Coil, Compression Adjustment (H and L Speed), Rebound Adjustment Rear Suspension Travel 305 mm / 12 inches Rake 27.4 ° Trail 116 mm / 4.57 inches Swingarm Aluminium Fabrication
Wheels & Brakes Wheels D.I.D. DirtStar aluminium spoked wheels Front Wheel/Rim Size 1.6 x 21″ Front Tire Size 80/100 – 21 Rear Wheel/Rim Size 2.15 x 19″ Rear Tire Size 110/90 – 19 Front Brakes Brembo Twin 24mm Piston, 260mm Disc Rear Brakes Brembo Single 26mm Piston, 220mm Disc
Dimension & Weights Overall Width 836 mm / 33 inches Overall Height 1270 mm / 50 inches Seat Height 960 mm / 37.8 inches Wheelbase 1492 mm / 58.74 inches Fuel Tank Capacity 7 L / 1.85 US gallons Wet (kerb/curb) Weight 108.6 kg / 239.42 lbs
Standard Equipment D.I.D Dirtstar rims Front disc guard Gripper seat cover MX Tune Pro smartphone app ODI Podium Flight RC4 Signature bars with half waffle lock on grips and bar pad Ricky Carmichael signature engine tune Standard Wi-Fi Comm module Triumph Racing Hinson clutch cover XTrig Holeshot device Triumph TF 450-RC (2025 – ) Color Options *We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
