The Moto Guzzi V7IIIMilano embodies the perfect blend of classic heritage and modern sophistication. Powered by a four-stroke, V-twin engine, this bike delivers a rich, throaty soundtrack and a smooth, effortless ride.
At the heart of the V7IIIMilano lies its longitudinally mounted, OHV engine, boasting two valves with light alloy pushrods and rockers. This powerplant is perfectly balanced by a die-cast alloy swing arm, paired with high-quality shocks and adjustable spring preload.
The V7IIIMilano’s sleek, modern appearance is elevated by its alloy wheels and luxurious details, including aluminium fenders and side fairings. As the latest iteration of the iconic V7 series, this bike promises an unforgettable riding experience that seamlessly combines tradition and innovation.
Key Specifications
Engine Type
Four stroke, V twin, longitudinally mounted, OHV,2 valves with light alloy pushrods and rockers
Engine Capacity
744 cc / 45.4 in
Max Power
38 kw / 52 hp
Max Torque
44.2 ft-lb / 60 nm
Fuel Tank Capacity
5.5 US gallons / 21.0 L
Weight (Wet/Kerb)
425 lbs / 193 kg
Seat Height
30.3 inches / 770 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V7IIIMilano
Year
2018 – 2019
Engine
Engine Type
Four stroke, V twin, longitudinally mounted, OHV,2 valves with light alloy pushrods and rockers
Displacement
744 cc / 45.4 in
Bore x Stroke
80 x 74 mm
Compression Ratio
9.6:1
Max Horsepower
38 kw / 52 hp
Max Torque
44.2 ft-lb / 60 nm
Engine Management System
Weber- Marelli electronic injection
Cooling System
Air cooled
Exhaust
3-way catalytic converter with double lambda probe
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Single disc, dry, with cush drive
Gearbox
6 Speed
Final Drive
Shaft
Electrical & Electronics System
Battery
12 V – 330 Watt Voltage 12 V – 14 Amph
Starter
Electric
Chassis & Suspension
Frame Type
Double cradle tubular frame. ALS steel. Detachable elements 1463 mm (57.6 inches)
Front Suspension
Marzocchi 40 mm telescopic front forks
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Die-cast alloy swing arm with 2 shocks with adjustable spring preload (hlins fully adjustable for Racer)
Rear Suspension Travel
3.6 inches / 93 mm
Rake
26.4
Trail
106 mm / 4.2 in
Wheels & Brakes
Front Tire Size
18″
Rear Tire Size
17″
Front Brakes
320 mm stainless steel floating discs, Brembo callipers with 4 differently sized opposed pistons
Rear Brakes
260 mm, stainless steel disc, floating calliper with 2 pistons
Dimension & Weights
Seat Height
30.3 inches / 770 mm
Wheelbase
56.8 inches / 1445 mm
Ground Clearance
150 mm / 5.9 in
Fuel Tank Capacity
5.5 US gallons / 21.0 L
Wet (kerb/curb) Weight
425 lbs / 193 kg
Features
Four stroke engine
V twin configuration
Longitudinally mounted engine
OHV valves
2 valves per cylinder
Light alloy pushrods and rockers
Die-cast alloy swing arm
2 shocks with adjustable spring preload
HLIN shocks fully adjustable for Racer model
Dual circular display instrumentation
Chromium exhaust
Passenger grab handle
Glossy tank colours
Alloy wheels
Aluminium fenders
Side fairings
50+ years of V7 history
Transversal V-twin engine configuration
Easy to ride and handle
Strong and authentic character
Entry-level model for Moto Guzzi
