Moto Guzzi V7 Stone (2013)

Moto Guzzi V7 Stone (2013)

The new Moto Guzzi V7 Stone is a masterclass in understated elegance, blending the timeless charm of classic Guzzi designs with the modern sophistication of a thoroughly updated package.

Its four-stroke V-twin engine, with two valves per cylinder, delivers a characteristic Guzzi sound and feel that’s equal parts raw and refined. The new lightweight alloy wheels aren’t just a nod to the past, but a forward-thinking innovation that slashes gyroscopic inertia by 30%, resulting in razor-sharp handling and exceptional agility.

The V7 Stone’s design is a loving tribute to the original V7s, with nods to the 750 Special and Sport models evident in every detail. The new tank is a particular highlight, with a more imposing presence and a superior material perception that’s unmistakably Italian.

The result is a bike that’s both a nostalgic throwback and a thoroughly modern riding experience.

Key Specifications

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Engine Capacity744 cc / 45.4 in
Max Power37.5 kw / 51 hp
Max Torque40.3 ft-lb / 58 nm
Fuel Tank Capacity22 Litres / 5.8 gal
Weight (Wet/Kerb)436 lbs / 198 kg
Seat Height31.7 inches / 805 mm
Moto Guzzi V7 Stone (2013)

All Specifications

Make & Model

ModelMoto Guzzi V7 Stone
Year2013

Engine

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Displacement744 cc / 45.4 in
Bore x Stroke80 x 74 mm
Compression Ratio9.6:1
Max Horsepower37.5 kw / 51 hp
Max Torque40.3 ft-lb / 58 nm
Engine Management SystemWeber- Marelli electronic injection
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchSingle disc, dry, with cush drive
Gearbox5 Speed
Gear Ratios1st 11/26 = 1 : 2.3636 2nd 14/23 = 1 : 1.6429 3rd 18/23 = 1 : 1.2778 4th 18/19 = 1 : 1.0556 5th 25/22 = 1 : 0.9
Final DriveShaft, ratio 4.825

Electrical & Electronics System

Battery12 V – 330 Watt Voltage 12 V – 14 Amp/h
StarterElectric

Chassis & Suspension

Frame TypeDetachabletubularduplexcradle
Front SuspensionMarzocchi 40 mm telescopic front forks
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionSwinging arm in light cast alloy with two dampers and adjustable preload
Rear Suspension Travel4.6 inches / 118 mm
Trail109 mm

Wheels & Brakes

WheelsCast aluminum alloy multi-spoke black anodized rims
Front Tire Size100/70-18
Rear Tire Size130/80-17
Front BrakesSingle 320mm disc 2 piston caliper
Rear BrakesSingle 260mm disc 2 piston caliper

Dimension & Weights

Seat Height31.7 inches / 805 mm
Wheelbase57.0 inches / 1449 mm
Fuel Tank Capacity22 Litres / 5.8 gal
Wet (kerb/curb) Weight436 lbs / 198 kg
Dry Weight179 kg / 395 lbs

Features

  • Four stroke engine
  • V twin cylinder configuration
  • Longitudinally mounted engine
  • OHV (Overhead Valve) engine design
  • 2 valves per cylinder
  • Swinging arm with two dampers and adjustable preload
  • Light cast alloy wheels
  • Six split spoke wheels design
  • Chromium plating on wheels
  • Metallic tones on wheels
  • Lightweight alloy wheels
  • Reduced weight at front (1440g)
  • Reduced weight at rear (860g)
  • Reduced gyroscopic inertia (30%)
  • Higher agility and speed entering turns
  • 22-litre fuel tank capacity
  • Metallic fuel tank
  • Record fuel tank capacity
  • Reduced consumption
  • Range of up to 500 km
  • Instrument panel with Veglia-Borletti inspired dials
