Moto Guzzi V7 Clubman Racer Verde Legnano Special Edition (2015)

The Moto Guzzi V7 Clubman Racer Verde Legnano Special Edition is a limited-edition tribute to the iconic 1971 Telaio Rosso Moto Guzzi V7 Sport.

This special edition bike features a stunning Verde Legnano green finish and a bold red frame, evoking the spirit of Lino Tonti’s groundbreaking design.

At the heart of this beauty lies a 748cc V-Twin engine, renowned for its rich, throaty soundtrack and its ability to deliver effortless acceleration and thrilling top-end performance.

As you ride the V7 Clubman Racer, you’ll be treated to an unforgettable experience, with its precise handling, responsive braking, and a deep, guttural growl that’s music to the ears.

Key Specifications

Engine Type	Four stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Engine Capacity	45.4 cubic inches / 744 cc
Max Power	48 hp / 35 kW @ 6200 rpm
Max Torque	40.3 ft-lb / 58 nm
Fuel Tank Capacity	17 Litres / 4.5 gal
Seat Height	31.7 inches / 805 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Moto Guzzi V7 Clubman Racer Verde Legnano Special Edition
Year	2015

Engine

Engine Type	Four stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Displacement	45.4 cubic inches / 744 cc
Bore x Stroke	80 x 74 mm
Compression Ratio	9.6:1
Max Horsepower	48 hp / 35 kW @ 6200 rpm
Max Torque	40.3 ft-lb / 58 nm
Engine Management System	Weber- Marelli electronic injection
Lubrication System	Wet sump, by lobes with pressure pump
Cooling System	Air cooled
Exhaust	3 ways catalyzed with sonda Lambda

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Single disc, dry, with cush drive
Gearbox	5 Speed
Gear Ratios	1st 11/26 = 1 : 2.3636 2nd 14/23 = 1 : 1.6429 3rd 18/23 = 1 : 1.2778 4th 18/19 = 1 : 1.0556 5th 25/22 = 1 : 0.9
Final Drive	Shaft, ratio 4.825

Electrical & Electronics System

Battery	12 V – 330 Watt Voltage 12 V – 14 Amp/h
Starter	Electric

Chassis & Suspension

Frame Type	Detachabletubularduplexcradle
Front Suspension	Marzocchi 40 mm telescopic front forks
Front Suspension Travel	5.1 inches / 130 mm
Rear Suspension	Swinging arm in light cast alloy with two dampers and adjustable preload
Rear Suspension Travel	4.6 inches / 118 mm
Rake	27.5
Trail	109 mm / 4.29 in

Wheels & Brakes

Wheels	Aluminium spoked black anodised rims
Front Tire Size	100/90/18
Rear Tire Size	130/80 17
Front Brakes	Single 320mm discs 4 piston calipers
Rear Brakes	Single 260mm disc 1 piston caliper

Dimension & Weights

Seat Height	31.7 inches / 805 mm
Wheelbase	57.0 inches / 1449 mm
Ground Clearance	182 mm / 7.2 in
Fuel Tank Capacity	17 Litres / 4.5 gal
Dry Weight	182 kg / 401.2 lbs

Features

748cc V-Twin engine
Longitudinally mounted engine
OHV (Overhead Valve) engine design
2 valves per cylinder
Swinging arm in light cast alloy
Two dampers for suspension
Adjustable preload on suspension
Special Verde Legnano green finish
Red frame
Chrome tank (replaced by classic green paint)
Black panel beneath the seat
Wet flywheel
Dry alternator (replaced by wet flywheel)
5-speed transmission
200 kg (440 lb.) dry weight
120 mph top speed
