Moto Guzzi V7 Clubman Racer (2012 – 2013)

Moto Guzzi V7 Clubman Racer (2012 - 2013)

The 2012-2013 Moto Guzzi V7 Clubman Racer embodies the essence of its legendary predecessors, combining style, substance, and a dash of modernity. This versatile model boasts a four-stroke, V-twin engine, paired with a longitudinally mounted, OHV system and 2 valves per cylinder, delivering a distinctive riding experience.

The V7 Clubman Racer’s design is a masterclass in understated elegance, with a plain color scheme and simple six-spoke wheels that enhance the chromium plating and metallic tones. The result is a bike that’s both timeless and modern, inviting owners to personalize their ride.

The lightweight alloy wheels, a notable innovation, reduce gyroscopic inertia by 30%, translating to enhanced agility and speed in corners. The V7 Clubman Racer’s riding philosophy is rooted in the original V7 concept, offering a touring bike with sophisticated finishings and exclusive technical solutions.

As a result, the V7 Clubman Racer excels on both short and long trips, providing a flagship riding range and a perfect canvas for customization, making it an ideal choice for riders who crave adventure and style.

Key Specifications

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Engine Capacity45.4 cubic inches / 744 cc
Max Power48 hp / 35 kW @ 6200 rpm
Max Torque40.3 ft-lb / 58 nm
Fuel Tank Capacity17 Litres / 4.5 gal
Seat Height31.7 inches / 805 mm
Moto Guzzi V7 Clubman Racer (2012 - 2013)

All Specifications

Make & Model

ModelMoto Guzzi V7 Clubman Racer
Year2012 – 2013

Engine

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Displacement45.4 cubic inches / 744 cc
Bore x Stroke80 x 74 mm
Compression Ratio9.6:1
Max Horsepower48 hp / 35 kW @ 6200 rpm
Max Torque40.3 ft-lb / 58 nm
Engine Management SystemWeber- Marelli electronic injection
Lubrication SystemWet sump, by lobes with pressure pump
Cooling SystemAir cooled
Exhaust3 ways catalyzed with sonda Lambda

Performance

Top Speedn/a

Transmission

ClutchSingle disc, dry, with cush drive
Gearbox5 Speed
Gear Ratios1st 11/26 = 1 : 2.3636 2nd 14/23 = 1 : 1.6429 3rd 18/23 = 1 : 1.2778 4th 18/19 = 1 : 1.0556 5th 25/22 = 1 : 0.9
Final DriveShaft, ratio 4.825

Electrical & Electronics System

Battery12 V – 330 Watt Voltage 12 V – 14 Amp/h
StarterElectric

Chassis & Suspension

Frame TypeDetachabletubularduplexcradle
Front SuspensionMarzocchi 40 mm telescopic front forks
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionSwinging arm in light cast alloy with two dampers and adjustable preload
Rear Suspension Travel4.6 inches / 118 mm
Rake27.5
Trail109 mm / 4.29 in

Wheels & Brakes

WheelsAluminium spoked black anodised rims
Front Tire Size110/90/18
Rear Tire Size130/80 17
Front BrakesSingle 320mm discs 4 piston calipers
Rear BrakesSingle 260mm disc 1 piston caliper

Dimension & Weights

Seat Height31.7 inches / 805 mm
Wheelbase57.0 inches / 1449 mm
Ground Clearance182 mm / 7.2 in
Fuel Tank Capacity17 Litres / 4.5 gal
Dry Weight182 kg / 401.2 lbs

Features

  • Four stroke engine
  • V twin configuration
  • Longitudinally mounted engine
  • OHV valve train
  • 2 valves per cylinder
  • Swing arm with 2 dampers and adjustable preload
  • Lightweight alloy wheels
  • Reduced gyroscopic inertia
  • Improved agility and speed entering turns
  • Precious spoked wheels with aluminium rims
  • Two-tone colour concept
  • Metal fuel tank
  • Commemorative plaque on the steering yoke
  • Leather strap
  • Red frame with special painting treatment
  • Colour-coded Moto Guzzi badge
  • Ultra sporty single-seater seat
  • New single throttle engine
  • Increased power and performance
  • Lower fuel consumption and greater tank capacity
