Moto Guzzi V7 Clubman Racer (2010 – 2011)

Moto Guzzi V7 Clubman Racer (2010 - 2011)

The Moto Guzzi V7 Clubman Racer is a tribute to the illustrious racing heritage of the V7 Sport, an icon of Italian motorcycle history. Its 90-degree V-twin engine, with two valves per cylinder and OHV configuration, provides a unique blend of power and character that is quintessentially Guzzi.

This beautiful machine is a masterclass in Italian style and craftsmanship, boasting a swingarm in light alloy with adjustable preload and a chromed tank that’s a work of art in itself. The V7 Racer’s design is a nod to the classic styling cues of the Moto Guzzi brand, perfectly balanced with cutting-edge technology.

On the road, the V7 Racer’s engine is a joy to behold, its torquey character and throaty exhaust note making it a true rider’s motorcycle. Whether you’re a collector, a enthusiast, or simply someone who appreciates the art of motorcycling, the V7 Racer is a truly unique experience that will leave you breathless and yearning for more. It’s a motorcycle that will make you feel like you’re part of a special club, where riding is an art form that’s cherished and celebrated.

Key Specifications

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Engine Capacity45.4 cubic inches / 744 cc
Max Power48 hp / 35 kW @ 6200 rpm
Max Torque40.3 ft-lb / 58 nm
Fuel Tank Capacity17 Litres / 4.5 gal
Seat Height31.7 inches / 805 mm
Moto Guzzi V7 Clubman Racer (2010 - 2011)

All Specifications

Make & Model

ModelMoto Guzzi V7 Clubman Racer
Year2010 – 2011

Engine

Engine TypeFour stroke, V twin, longitudinally mounted, OHV, 2 valves per cylinder.
Displacement45.4 cubic inches / 744 cc
Bore x Stroke80 x 74 mm
Compression Ratio9.6:1
Max Horsepower48 hp / 35 kW @ 6200 rpm
Max Torque40.3 ft-lb / 58 nm
Engine Management SystemWeber- Marelli electronic injection
Lubrication SystemWet sump, by lobes with pressure pump
Cooling SystemAir cooled
Exhaust3 ways catalyzed with sonda Lambda

Performance

Top Speedn/a

Transmission

ClutchSingle disc, dry, with cush drive
Gearbox5 Speed
Gear Ratios1st 11/26 = 1 : 2.3636 2nd 14/23 = 1 : 1.6429 3rd 18/23 = 1 : 1.2778 4th 18/19 = 1 : 1.0556 5th 25/22 = 1 : 0.9
Final DriveShaft, ratio 4.825

Electrical & Electronics System

Battery12 V – 330 Watt Voltage 12 V – 14 Amp/h
StarterElectric

Chassis & Suspension

Frame TypeDetachabletubularduplexcradle
Front SuspensionMarzocchi 40 mm telescopic front forks
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionSwinging arm in light cast alloy with two dampers and adjustable preload
Rear Suspension Travel4.6 inches / 118 mm
Rake27.5
Trail109 mm / 4.29 in

Wheels & Brakes

WheelsAluminium spoked black anodised rims
Front Tire Size110/90/18
Rear Tire Size130/80 17
Front BrakesSingle 320mm discs 4 piston calipers
Rear BrakesSingle 260mm disc 1 piston caliper

Dimension & Weights

Seat Height31.7 inches / 805 mm
Wheelbase57.0 inches / 1449 mm
Ground Clearance182 mm / 7.2 in
Fuel Tank Capacity17 Litres / 4.5 gal
Dry Weight182 kg / 401.2 lbs

Features

  • Four stroke engine
  • V twin configuration
  • Longitudinally mounted engine
  • OHV (Over Head Valve) design
  • 2 valves per cylinder
  • Light cast alloy swinging arm
  • Two dampers and adjustable preload
  • Chromed tank with metal particle deposition technology
  • Leather strap on tank
  • Metal accents on Moto Guzzi badge
  • Colour-coded Moto Guzzi badge with frame
  • Red frame with CrMo construction
  • Gloss finish on frame, hubs, and swingarm
  • Ultra sporty single-seater saddle
  • Suede upholstered saddle
  • Aerodynamic tail fairing
  • Lateral race number panels
  • Tiny Plexiglas screen above race number panel
  • Top fairing with Guzzi school design
  • Double cradle structure
