The Moto Guzzi V-7750 Ambassador is a majestic ride that embodies the spirit of the open road. Its four-stroke, 90-degree V-twin engine is a marvel of engineering, delivering a distinctive rumble that’s music to the ears. With its longitudinally mounted design, the powerplant is the heartbeat of this classic machine, pumping out a healthy dose of torque that makes it feel like a lion unleashed on the highway.
The Ambassador’s riding experience is sublime, with a comfortable, laid-back stance that invites you to take your time and soak up the scenery. The enlarged fuel tank and strengthened frame provide a sense of solidity and dependability, while the smooth-shifting transmission lets you glide effortlessly through the gears.
But make no mistake, this is a bike that’s more than just a pretty face. With its robust engine and rugged build, the Moto Guzzi V-7750 Ambassador is a true adventurer’s companion, ready to tackle the long haul with ease and aplomb. And with its rich heritage and countless miles of happy memories behind it, this iconic bike is sure to leave an indelible mark on your heart.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Engine Capacity
45.6 cubic inches / 748.4 cc
Max Power
62 hp / 46.2 kW @ 7250 rpm
Max Torque
NA
Fuel Tank Capacity
5.9 US gallons / 22.5 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V-7750 Ambassador
Year
1970
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Displacement
45.6 cubic inches / 748.4 cc
Bore x Stroke
83 x 70 mm
Compression Ratio
9.8:1
Max Horsepower
62 hp / 46.2 kW @ 7250 rpm
Max Torque
NA
Engine Management System
2x 30mm Dell’Orto VHB 30CD carburetors
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
4 Speed contant mesh
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telehydraulic forks
Rear Suspension
Swinging arm with hydraulic dampers preload adjustable
Wheels & Brakes
Front Tire Size
90/90-18
Rear Tire Size
110/90-18
Front Brakes
2x Leading shoe drum
Rear Brakes
Single leading shoe drum
Dimension & Weights
Fuel Tank Capacity
5.9 US gallons / 22.5 L
Dry Weight
227 kg / 500 lbs
Features
Four stroke engine
90 V twin configuration
Longitudinally mounted engine
OHV (Overhead Valve) design
2 valves per cylinder
757cc displacement
83mm bore
Larger valves
Dual valve springs
Enlarged fuel tank
Lengthened and strengthened frame
Right-side gearshift (V7 Special)
Left-side gearshift (US Ambassador)
Produced until 1974
Over 12,000 units produced
Police version available
