The Moto Guzzi V 75 embodies the essence of Italian motorcycle design, marrying sleek lines with a robust V-twin engine. This longitudinally mounted powerplant features an overhead valve configuration and a generous 4 valves per cylinder, ensuring a rich, throaty exhaust note that’s as distinctive as it is addictive.
The V 75’s engine character is a masterclass in balance and refinement, delivering a smooth, linear power delivery that belies its 750cc displacement. Whether carving through twisties or cruising down the highway, the Moto Guzzi V 75 is a true master of its class.
With its exceptional blend of performance and poise, the V 75 stands as a testament to Guzzi’s commitment to creating motorcycles that are at once thrilling and refined, making it a true standout in the world of two-wheeled transportation.
Key Specifications
Engine Type
Four stroke, V twin, longitudinally mounted, OHV, 4 valves per cylinder.
Engine Capacity
45.3 cubic inches / 744 cc
Max Torque
45.5 ft-lb / 61.6 nm
Fuel Tank Capacity
4.5 US gallons / 17.0 L
Weight (Wet/Kerb)
421 lbs / 191 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V 75
Year
1985
Engine
Engine Type
Four stroke, V twin, longitudinally mounted, OHV, 4 valves per cylinder.
Displacement
45.3 cubic inches / 744 cc
Bore x Stroke
84 x 74 mm
Compression Ratio
10.2:1
Max Torque
45.5 ft-lb / 61.6 nm
Engine Management System
2x 30mm PHBH Dell’Orto carburetors
Lubrication System
Pressure pump
Cooling System
Air cooled
Performance
Top Speed
188.7 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Single plate, dry type
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Steel tubular duplex cradle, disassemblable
Front Suspension
Telescopic air assisted forks
Rear Suspension
Marzocchi 5-way preload adjustment,
Wheels & Brakes
Front Tire Size
110/90 B16
Rear Tire Size
120/80 H18
Front Brakes
2x 270mm disc
Rear Brakes
Single 235mm disc
Dimension & Weights
Fuel Tank Capacity
4.5 US gallons / 17.0 L
Wet (kerb/curb) Weight
421 lbs / 191 kg
Dry Weight
175 kg / 398 lbs
Features
Four-stroke engine
V-twin configuration
Longitudinally mounted engine
Overhead valve (OHV) design
4 valves per cylinder
