The Moto Guzzi V50 Monza, a middleweight marvel from the early 1980s, boasts a four-stroke, 90-degree V-twin engine with a longitudinally mounted, OHV configuration and two valves per cylinder.
This compact and lightweight motorcycle was the result of Lino Tonti’s innovative design, which retained the traditional V-twin layout while incorporating several technical advances over the larger twins.
The V50 Monza’s engine features a chain-driven central camshaft and pushrod-operated valves, with a dry clutch that utilizes one friction plate and a diaphragm spring for minimal spline wear and a smoother action.
With its Herron head design and high compression ratios, the V50 Monza delivers excellent fuel economy, but its small valves and sharply curved ports do restrict ultimate breathing.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Engine Capacity
29.9 cubic inches / 490 cc
Max Power
48 hp / 35.7 kW @ 7500 rpm
Max Torque
NA
Fuel Tank Capacity
4.2 US gallons / 16.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V 50 Monza
Year
1981
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Displacement
29.9 cubic inches / 490 cc
Bore x Stroke
74 x 57 mm
Compression Ratio
10.4:1
Max Horsepower
48 hp / 35.7 kW @ 7500 rpm
Max Torque
NA
Engine Management System
2x 28mm Dell’Orto PHBH carbs
Cooling System
Air cooled
Performance
Top Speed
172 km/h / 107 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry single plate
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telehydraulic gas forks
Rear Suspension
Swinging arm fork with hydraulic gas shock absorbers
Wheels & Brakes
Front Tire Size
3.25-18
Rear Tire Size
3.50-18
Front Brakes
2x 260mm disc
Rear Brakes
Single 235mm disc
Dimension & Weights
Fuel Tank Capacity
4.2 US gallons / 16.0 L
Dry Weight
160 kg / 353 lbs
Features
90-degree V-twin engine
Longitudinally mounted engine
OHV (overhead valve) design
2 valves per cylinder
Dry clutch with one friction plate and diaphragm spring
Helical primary gears
Intermediate housing between engine and gearbox
Alloy swingarm
Pivoting on rear of 5-speed gearbox
Detachable lower section frame
Air-assisted forks
Twin shock absorbers
Triple integrated disc brakes
Engine finning
75x57mm engine dimensions
Larger valves in sporting versions
Dellorto PHBH 28B carburettors in sporting versions
Power increased to 48bhp at 7,000rpm in sporting versions
