The Moto Guzzi V 50 II is a rare gem, a 500cc roadster that embodies the essence of Italian design and engineering. Its longitudinally mounted 90-degree V-twin engine, with its characteristic air-cooled charm, is a marvel of simplicity and elegance. With its 4 valves per cylinder and OHV configuration, the V50-II delivers a unique riding experience, one that is both refined and expressive. As you twist the throttle, the V50-II comes alive, its engine note a symphony of rich, full-bodied tones that are quintessentially Guzzi.
The V50-II is a bike that defies easy categorization, blending the best of Italian design with the ruggedness of a true roadster. Its dry clutch and shaft-driven transmission provide a smooth, effortless power delivery, while its Bosch electrics and electronic ignition ensure a reliable and hassle-free ownership experience.
As a testament to Moto Guzzi’s commitment to innovation, the V50-II is a bike that stands apart from its contemporaries, a true original that will captivate and inspire even the most discerning motorcyclist. Whether you’re a seasoned collector or a newcomer to the world of two-wheeled passion, the Moto Guzzi V 50 II is an experience you won’t soon forget.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder
Engine Capacity
29.9 cubic inches / 490 cc
Max Power
48 hp / 35.7 kW @ 7500 rpm
Max Torque
NA
Fuel Tank Capacity
4.3 US gallons / 16.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V 50 II
Year
1979 – 80
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder
Displacement
29.9 cubic inches / 490 cc
Bore x Stroke
74 x 57 mm
Compression Ratio
10.8:1
Max Horsepower
48 hp / 35.7 kW @ 7500 rpm
Max Torque
NA
Engine Management System
2x 24mm Dell’Orto carburetors
Cooling System
Air cooled
Performance
Top Speed
103 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry single plate
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Duplex spine type
Front Suspension
Telehydraulic gas forks
Rear Suspension
Swinging arm fork with hydraulic gas shock absorbers
Wheels & Brakes
Front Tire Size
3.60-18
Rear Tire Size
4.10-18
Front Brakes
2x 270mm discs
Rear Brakes
Single 235mm disc
Dimension & Weights
Fuel Tank Capacity
4.3 US gallons / 16.0 L
Dry Weight
158 kg / 348 lbs
Features
Four stroke engine
90 V twin engine
Longitudinally mounted engine
OHV (Overhead Valve) design
4 valves per cylinder
Air cooled
Bosch electrics
Electronic ignition
24mm Dell’Orto carb
Accelerator pump
Plain bearings on the crank
Wet sump
Horizontally split crankcase
Externally-removable cartridge oil filter
Chain driven camshaft
Electronic ignition advance based on engine speed
Separate transmission
Dry clutch
Power delivered via shaft to the rear hub
