Moto Guzzi V 11 Sport Ballabio (2002 – 2003)

Moto Guzzi V 11 Sport Ballabio (2002 - 2003)

The Moto Guzzi V11 Sport Ballabio is a testament to the Italian marque’s rich heritage in motorcycle racing. Named after the legendary Ballabio-Resinelli hillclimb, this bike embodies the very essence of what makes a machine truly exceptional on twisty mountain roads.

Its 90-degree V-twin engine is a masterclass in balance and power delivery, thanks to the addition of a crossover pipe and increased compression ratio to 9.8:1. This results in a thrilling riding experience, with bags of torque available at low revs and a silky-smooth power delivery that’s simply intoxicating.

Handling is razor-sharp, thanks to a sensitive front end and Brembo Gold Series brakes that provide reassuring stopping power. The V11 Sport Ballabio is a true performance machine that will leave even the most seasoned riders grinning from ear to ear.

Available in striking red and black liveries, this limited-edition bike is a collector’s dream come true, and a fitting tribute to the legendary Ballabio-Resinelli hillclimb that inspired it.

Key Specifications

Engine TypeFour stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Engine Capacity64.9 cubic inches / 1064 cc
Max Power91 hp / 66.3 kW @ 7800 rpm
Max Torque69.3 ft-lb / 94 nm
Fuel Tank Capacity5.8 US gallons / 22.0 L
Seat Height31.5 inches / 800 mm
Moto Guzzi V 11 Sport Ballabio (2002 - 2003)

All Specifications

Make & Model

ModelMoto Guzzi V 11 Sport Ballabio
Year2002 – 2003

Engine

Engine TypeFour stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Displacement64.9 cubic inches / 1064 cc
Bore x Stroke92 x 80 mm
Compression Ratio9.8:1
Max Horsepower91 hp / 66.3 kW @ 7800 rpm
Max Torque69.3 ft-lb / 94 nm
Engine Management SystemMagneti Marelli IAW Multipoint phased sequential fuel injection
Cooling SystemAir cooled

Performance

Top Speed229.3 km/h

Transmission

Gearbox5 Speed
Final DriveShaft

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Front Suspension40mm Marzocchi upside-down forks, adjustable compression
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionCantilever swingarm, Sachs Boge mono shock, adjustable compression and rebound damping
Rear Suspension Travel5.0 inches / 128 mm

Wheels & Brakes

Front Tire Size120/70-17
Rear Tire Size180/55-17
Front Brakes2x 320mm discs 4 piston calipers
Rear BrakesSingle 282mm disc 2 piston caliper

Dimension & Weights

Overall Height1090 mm / 42.9 in
Seat Height31.5 inches / 800 mm
Wheelbase57.9 inches / 1471 mm
Fuel Tank Capacity5.8 US gallons / 22.0 L
Dry Weight221 kg /487.2 lbs

Features

  • 90 V twin engine
  • Longitudinally mounted engine
  • OHV (Overhead Valve) design
  • 4 valves per cylinder
  • Increased compression ratio of 9.8:1
  • Brembo Gold Series brakes
  • 180/55 17″ rear tire
  • Available in Red and Black
  • Marzocchi 43 mm upside-down fork
  • Adjustable rebound and preload on front fork
  • Sachs monoshock rear suspension
  • Adjustable compression, rebound, and spring preload on rear suspension
  • Die-cast cantilever swinging arm
  • Ultra-lightweight alloy rear suspension arm
  • Euro 2 emission standards compliance
  • 3-way Lambda probe catalyser
  • Upright riding position
  • Raised, double tapered, aluminium handlebars
  • Improved sports handling and natural riding position
