The Moto Guzzi V1000G5 is a stalwart of the Italian marque’s rich history, boasting a distinctive longitudinally mounted 90-degree V-twin engine. This innovative layout allows for a remarkably compact and balanced powerplant, with each cylinder benefiting from a dedicated camshaft for improved breathing and refinement.
The result is a motor that effortlessly delivers its 80 horsepower, with a smooth, linear power delivery that is at once tractable and rewarding. Whether carving through mountain roads or devouring the open highway, the V1000G5’s engine is a masterclass in understated yet effective engineering.
The riding experience is characterized by its fluidity and poise, as the Guzzi’s longitudinal engine design imbues the motorcycle with a unique sense of balance and stability.
Key Specifications
Engine Type
Four stroke, 90V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Engine Capacity
57.9 cubic inches / 949 cc
Max Power
67 hp / 49 kW @ 6700 rpm
Max Torque
47.7 ft-lb / 64.6 nm
Fuel Tank Capacity
6.3 US gallons / 24.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi V 1000G5
Year
1981 – 85
Engine
Engine Type
Four stroke, 90V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Displacement
57.9 cubic inches / 949 cc
Bore x Stroke
88 x 78 mm
Compression Ratio
9.2:1
Max Horsepower
67 hp / 49 kW @ 6700 rpm
Max Torque
47.7 ft-lb / 64.6 nm
Engine Management System
2x Dell’Orto VHB30 CD/CS carburetors
Lubrication System
By pressure pump
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry multi plate
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Duplex cradle, disassemblable
Front Suspension
Telescopic forks
Rear Suspension
Swinging fork
Wheels & Brakes
Front Tire Size
100/90 H18
Rear Tire Size
110/90 H18
Front Brakes
2x 300mm discs
Rear Brakes
Single 242mm disc
Dimension & Weights
Fuel Tank Capacity
6.3 US gallons / 24.0 L
Dry Weight
220 kg / 486 lbs
Features
Four stroke
90V twin
Longitudinally mounted
OHV
2 valve per cylinder
