The highly anticipated Moto Guzzi Stelvio has finally arrived, marking the next chapter in the brand’s illustrious history. This state-of-the-art motorcycle embodies the perfect blend of cutting-edge technology and timeless design, paying homage to the company’s rich heritage.
The Stelvio boasts an impressive list of features, including a hydraulically actuated wet multiplate clutch with assist and slipper functions, as well as a Sachs 46mm inverted fork with adjustable spring-preload and rebound-damping. The Aluminum single-sided shock absorber on the left side is also adjustable in spring preload with a knob and rebound hydraulics, ensuring a smooth ride on any terrain.
But what truly sets the Stelvio apart is its powerful liquid-cooled 90-degree V-twin engine, providing a unique and thrilling riding experience. With its distinctive engine character, the Stelvio delivers an unparalleled level of excitement and adventure, inviting seasoned motorcyclists to push the limits and explore new horizons.
As the ultimate destination for the seasoned motorcyclist, the Moto Guzzi Stelvio is an opportunity to ascend to the peak of riding pleasure, with its perfectly balanced handling and responsive power delivery making it the perfect companion for endless journeys through the twists and turns of the world’s most iconic roads.
Key Specifications
Engine Type
Four stroke, transversal 90 V-twin, DOHC, timing with finger followers, longitudinal crank, 4 valves per cylinder
Engine Capacity
63.5 cubic inches / 1042 cc
Max Torque
77 ft-lb / 104.3 nm
Fuel Tank Capacity
5.5 US gallons / 20.8 L
Weight (Wet/Kerb)
542 lbs / 246 kg
Seat Height
32.7 inches / 830 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi Stelvio
Year
2024
Engine
Engine Type
Four stroke, transversal 90 V-twin, DOHC, timing with finger followers, longitudinal crank, 4 valves per cylinder
Displacement
63.5 cubic inches / 1042 cc
Bore x Stroke
96 x 72 mm
Compression Ratio
12.6:1
Max Torque
77 ft-lb / 104.3 nm
Engine Management System
Electronic injection, 52 mm double throttle body, Ride-by-Wire
Cooling System
Liquid-cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Hydraulically actuated wet multiplate w/ assist and slipper functions
Gearbox
6-Speed quickshifter optional
Final Drive
Shaft: Drive ratio: 12/38 (3.166)
Electrical & Electronics System
Starter
Electric
ABS
Cornering-aware Continental ABS
Chassis & Suspension
Frame Type
Tubular steel
Front Suspension
Sachs 46mm inverted fork, Spring-preload and rebound-damping adjustable
Front Suspension Travel
6.8 inches / 170 mm
Rear Suspension
Aluminum single-sided shock absorber left side, adjustable in spring preload with knob and rebound hydraulics
Rear Suspension Travel
6.8 inches / 170 mm
Rake
25.6
Trail
116.49 mm / 4.59 in
Wheels & Brakes
Wheels
Spoked
Front Wheel/Rim Size
3.00 x 19
Front Tire Size
120/70 R19
Rear Wheel/Rim Size
4.50 x 17
Rear Tire Size
170/60 R17
Front Brakes
2x 320 mm floating discs, radially mounted Brembo 4-piston calipers and steel-braided brake lines
Rear Brakes
Single 280 mm disc, 2-piston Brembo caliper
ABS
Cornering-aware Continental ABS
Dimension & Weights
Overall Length
2195 mm / 86.4 in
Overall Width
945 mm / 37.2 in
Seat Height
32.7 inches / 830 mm
Wheelbase
59.8 inches / 1520 mm
Fuel Tank Capacity
5.5 US gallons / 20.8 L
Wet (kerb/curb) Weight
542 lbs / 246 kg
Dry Weight
222 kg / 489 lbs
Features
Hydraulically actuated wet multiplate clutch with assist and slipper functions
Sachs 46mm inverted fork, adjustable in spring preload and rebound damping
Aluminum single-sided shock absorber, adjustable in spring preload with knob and rebound hydraulics
Liquid-cooled 90 transverse V-twin engine
Electrically height-adjustable windshield
Cardan shaft drive
Peerless performance attributes
Distinctive sound
Unique 90 transverse V-twin engine configuration
Transverse V-twin engine with 90-degree configuration
Electrically adjustable windshield
Inverted fork with adjustable preload and rebound damping
Single-sided shock absorber with adjustable preload
Advanced aerodynamics
Distinctive design with sculptured engine
Unmistakable Moto Guzzi style and design philosophy
