The Moto Guzzi Stelvio 1200 4V is a formidable motorcycle that embodies the perfect blend of style, substance, and off-road capability. Its sleek and aerodynamic design is inspired by the world of off-road bikes, yet it still exudes a sense of sophistication and refinement.
At the heart of this machine lies the 90-degree V-twin engine, a masterpiece of Italian engineering that delivers a rich and throaty sound, as well as a significant amount of power and torque. This potent powerplant is perfectly suited to the Stelvio’s adventurous spirit, allowing riders to tackle even the most challenging terrain with confidence and ease.
The Stelvio 1200 4V’s capabilities are further enhanced by its robust suspension system, which features a single-sided swing-arm with progressive linkage and monoshock, as well as adjustable hydraulic rebound and preload. This, combined with the bike’s compact and robust design, ensures that the Stelvio 1200 4V is a true master of the road and trail.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Engine Capacity
70.2 cubic inches / 1151 cc
Max Power
102 hp / 75 kW @ 7000 rpm
Max Torque
83.3 ft-lb / 110 nm
Fuel Tank Capacity
18 Litres / 4.7 gal
Seat Height
820 – 840 mm / 32 33 in adjustable
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi Stelvio 1200
Year
2009
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Displacement
70.2 cubic inches / 1151 cc
Bore x Stroke
95 x 81.2 mm
Compression Ratio
11.0:1
Max Horsepower
102 hp / 75 kW @ 7000 rpm
Max Torque
83.3 ft-lb / 110 nm
Engine Management System
Weber-Marelli electronic fuel injection with stepper motor control
Cooling System
Air cooled
Exhaust
Stainless steel, 2-in-1 type, three-way catalytic converter with lambda probe
