Moto Guzzi Nevada 750 (2011 – 2012)

Moto Guzzi Nevada 750 (2011 - 2012)

The Moto Guzzi Nevada 750 embodies the perfect blend of classic style and modern performance, making it an ideal choice for riders of all backgrounds and experience levels. Powered by a 90-degree V-twin engine, this longitudinally-mounted powerhouse delivers increased power and torque while minimizing fuel consumption and emissions.

The Nevada’s riding position is a key highlight, offering a more upright and comfortable stance than traditional customs, allowing riders to maintain greater control and agility. This unique blend of style and substance makes the Nevada an excellent choice for long-range touring, and its low weight and fuel efficiency make it an attractive option for female riders and commuters alike.

With its sleek “Aquila Nera” livery and array of optional accessories, including side bags, top box, and windshield, the Nevada Classic transforms into a comfortable and practical Grand Tourism bike. The new single throttle two-cylinder engine is the perfect match for this iconic model, delivering a thrilling riding experience that is sure to leave a lasting impression.

Key Specifications

Engine TypeFour stroke, 90 V twin, longitudinally mounted, OHV, 2 valves per cylinder
Engine Capacity45.4 cubic inches / 744 cc
Max Power35.5kW/48kW @6600rpm
Max Torque40.3 ft-lb / 54.7 nm
Fuel Tank Capacity3.7 US gallons / 14.0 L
Seat Height30.0 inches / 767 mm
Moto Guzzi Nevada 750 (2011 - 2012)

All Specifications

Make & Model

ModelMoto Guzzi Nevada 750
Year2011 – 2012

Engine

Engine TypeFour stroke, 90 V twin, longitudinally mounted, OHV, 2 valves per cylinder
Displacement45.4 cubic inches / 744 cc
Bore x Stroke80 x 74 mm
Compression Ratio9.6:1
Max Horsepower35.5kW/48kW @6600rpm
Max Torque40.3 ft-lb / 54.7 nm
Engine Management SystemWeber-Marelli electric injection
Lubrication SystemBy lobes with pressure pump
Cooling SystemAir cooled
ExhaustThree-way catalyzer with Lambda sensor

Performance

Top Speedn/a

Transmission

ClutchSingle disc, dry, with cush drive
Gearbox5 Speed
Gear Ratios1st 11/26 = 1 : 2,3636 2nd 14/23 = 1 : 1,6429 3rd 18/23 = 1 : 1,2778 4th 18/19 = 1 : 1,0556 5th 25/22 = 1 : 0,88
Final DriveShaft

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeDetachable tubular duplex cradle in special high-strengh steel
Front Suspension40mm Marzocchi hydraulic telescopic fork
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionSwinging fork in light alloy cast with two dampers and spring adjustable for preload and rebound
Rear Suspension Travel5.1 inches / 130 mm
Rake27.5
Trail135 mm / 5.4 in

Wheels & Brakes

Front Tire Size100/90 V18
Rear Tire Size130/90 V16
Front BrakesSingle 320mm disc 4 piston caliper
Rear BrakesSingle 260mm disc 1 piston caliper

Dimension & Weights

Seat Height30.0 inches / 767 mm
Wheelbase57.8 inches / 1467 mm
Fuel Tank Capacity3.7 US gallons / 14.0 L
Dry Weight184 kg /405.7 lbs

Features

  • 90 V twin, longitudinally mounted, OHV, 2 valves per cylinder engine
  • Four stroke engine
  • Single throttle
  • Increased power
  • Increased torque
  • Decreased fuel consumption
  • Decreased emissions
  • Faultless chassis
  • Low saddle
  • Wide handlebars
  • Moderately forward placed footrests
  • Riding position for greater control
  • Suitable for female riders
  • Low weight and agility
  • Available for long range touring
  • Side bags available
  • Top box available
  • Windshield available
  • Final cardan joint drive
