The Moto Guzzi Nevada 750 is a testament to the Italian marque’s rich heritage in crafting iconic motorcycles. At its heart lies a robust 90° V-twin engine, a configuration that Guzzi has mastered over the years. With an overhead valve configuration and two valves per cylinder, the engine produces a smooth, linear power delivery that’s perfectly suited for urban riding.
Its longitudinally mounted layout contributes to the bike’s exceptional handling and stability, while the 748cc engine produces a generous 56 horsepower, making it an ideal companion for both daily commutes and spirited weekend rides.
On the road, the Nevada 750’s engine sings a sweet, throaty tune as it effortlessly navigates the urban jungle, its rider enjoying an engaging experience that’s both relaxing and thrilling.
Key Specifications
Engine Type
Four stroke, 90V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Engine Capacity
45.4 cubic inches / 744 cc
Max Power
45 hp / 38 kW @ 6800 rpm
Max Torque
43.8 ft-lb / 4 nm
Fuel Tank Capacity
4.3 US gallons / 16.5 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi Nevada 750
Year
1990 – 93
Engine
Engine Type
Four stroke, 90V twin, longitudinally mounted, OHV, 2 valve per cylinder.
Displacement
45.4 cubic inches / 744 cc
Bore x Stroke
84 x 74 mm
Compression Ratio
9.7:1
Max Horsepower
45 hp / 38 kW @ 6800 rpm
Max Torque
43.8 ft-lb / 4 nm
Engine Management System
2x Dell’Orto PHBH 28 carburetors
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5Speed
Final Drive
Shaft
Electrical & Electronics System
Chassis & Suspension
Front Suspension
Moto Guzzi hydropneumatic telescopic fork with pressure equalizer
Rear Suspension
Swinging fork, light alloy die-casting, with Bitubo adjustable shock-absorber
Wheels & Brakes
Wheels
Spokes with light a
Front Tire Size
100 90 V18
Rear Tire Size
130/90 V16
Front Brakes
2x 270mm discs
Rear Brakes
Single 260mm disc
Dimension & Weights
Fuel Tank Capacity
4.3 US gallons / 16.5 L
Dry Weight
177 kg / 390 lbs
Features
Four stroke engine
90V twin cylinder
Longitudinally mounted engine
OHV (Overhead Valve) design
2 valves per cylinder
