Moto Guzzi MGS-01 Corsa (2004 – 2005)

Moto Guzzi MGS-01 Corsa (2004 - 2005)

The Moto Guzzi MGS-01 Corsa is a testament to the Italian manufacturer’s commitment to innovation and design excellence. Born from the collaboration between Moto Guzzi and renowned designers Ghezzi & Brian, this sleek and agile motorcycle is the culmination of a two-year development process.

With a potent four-valve twin engine and a six-speed transmission, the MGS-01 Corsa is a masterclass in engine design, delivering a unique blend of power and smoothness. The shaft drive and exposed mechanics are a deliberate design choice, evoking the raw emotion and character of a true motorcycle.

As you ride the MGS-01 Corsa, you’ll be struck by its exceptional handling and balance, making it a joy to carve through twisty roads and corners. With its short wheelbase and razor-sharp steering, this bike is a true thrill-seeker’s delight. The result is a riding experience that is both exhilarating and accessible, making the MGS-01 Corsa an irresistible choice for enthusiasts and collectors alike.

Key Specifications

Engine TypeAir cooled, four stroke, V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Engine Capacity76.6 cubic inches / 1225 cc
Max Power122 hp /89.1kW @ 8000 rpm
Max Torque83.2 lb-ft /112.8Nm @ 640 rpm
Fuel Tank Capacity5.2 US gallons / 20.0 L
Seat Height32.3 inches / 820 mm
Moto Guzzi MGS-01 Corsa (2004 - 2005)

All Specifications

Make & Model

ModelMoto Guzzi MGS-01 Corsa
Year2004 – 2005

Engine

Engine TypeAir cooled, four stroke, V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Displacement76.6 cubic inches / 1225 cc
Bore x Stroke100 x 78 mm
Compression Ratio11.0;1
Max Horsepower122 hp /89.1kW @ 8000 rpm
Max Torque83.2 lb-ft /112.8Nm @ 640 rpm
Engine Management System50mm Marelli infection

Performance

Top Speedn/a

Transmission

Final DriveShaft

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeRectangular section single-beam
Front Suspension43mm hlins upside-down forks, adjustable compression
Front Suspension Travel4.7 inches / 120 mm
Rear Suspensionaluminium-plate swinging fork with hlins shock absorber, fully adjustable
Rear Suspension Travel4.3 inches / 110 mm
Rake23.5
Trail95 mm / 3.7 in

Wheels & Brakes

Front Tire Size120/70 -17
Rear Tire Size180/55 -17
Front Brakes2x 320mm discs 4 piston calipers
Rear BrakesSingle 282mm disc 2 piston caliper

Dimension & Weights

Seat Height32.3 inches / 820 mm
Wheelbase56.2 inches / 1428 mm
Fuel Tank Capacity5.2 US gallons / 20.0 L
Dry Weight192 kg /423.3 lbs

Features

  • Four-valve twin engine
  • Six-speed transmission
  • Shaft drive
  • Exposed mechanics
  • Short wheelbase
  • Excellent balance
  • Racing mechanics
  • Lightweight components
  • Swinging fork swingarm in box-type aluminium
  • Rectangular cross-section steel single spar frame
  • High-performance Hlins suspension
  • Ultra-modern interpretation of the Moto Guzzi spirit
  • Sleek lines and aggressive design
  • Easy to ride
  • Communicates personality of the bike immediately
  • Rider-focused design
  • Simple and “pure” design
  • Concentrated on ridability and handling
  • Excellent handling and rigidity
