Moto Guzzi California Eldorado (2015 – 2016)

Moto Guzzi California Eldorado (2015 - 2016)

The Moto Guzzi California Eldorado is a testament to the enduring spirit of Italian motorcycle design, where the past and present converge in a symphony of style and performance. This luxurious V-twin, boasting the iconic 90-degree engine configuration, is a modern interpretation of the classic Eldorado, first introduced to the US market in the late 1960s.

With a nod to the gods of ancient Rome, the Eldorado embodies the essence of Bacchus – a celebration of power, luxury, and unbridled freedom. The bike’s design is a masterful blend of nostalgic charm and cutting-edge technology, evident in its sleek lines, chrome accents, and precision-crafted details.

As you saddle up and hit the open road, the Eldorado’s 90-degree V-twin engine comes alive, its rich exhaust note and effortless power delivery making it a joy to ride. With its lower riding position, thanks to the new 16-inch spoke wheels, and generous wraparound mudguards, the Eldorado exudes a sense of sophistication and refinement.

In the end, the Moto Guzzi California Eldorado is a motorcycle that will leave you breathless, its intoxicating blend of style, performance, and Italian flair making it an unforgettable riding experience.

Key Specifications

Engine TypeFour stroke, 90 V-twin, SOHC, 4 valves per cylinder
Engine Capacity84.2 cubic inches / 1380 cc
Max Power71 kw / 96 hp
Max Torque120 Nm / 12.1 kgf-m / 89 ft/lb @ 2750 rpm
Fuel Tank Capacity4.7 US gallons / 20.5 L
Seat Height29.1 inches / 740 mm
Moto Guzzi California Eldorado (2015 - 2016)

All Specifications

Make & Model

ModelMoto Guzzi California Eldorado
Year2015 – 2016

Engine

Engine TypeFour stroke, 90 V-twin, SOHC, 4 valves per cylinder
Displacement84.2 cubic inches / 1380 cc
Bore x Stroke104 x 81.2 mm
Compression Ratio10.5:1
Max Horsepower71 kw / 96 hp
Max Torque120 Nm / 12.1 kgf-m / 89 ft/lb @ 2750 rpm
Lubrication SystemWet sump
Cooling SystemAir and oil cooled
ExhaustStainless steel, 2-in-2 type, three-way catalytic converter with double oxygen sensor, Euro 3

Performance

Top Speedn/a

Transmission

ClutchSingle-disc with integrated anti-vibration buffer
Gearbox6 speed with final overdrive
Gear Ratios1st 17:38 = 1:2.235 / 2nd 20:34 = 1:1.700 / 3rd 23:31 = 1:1.348 / 4th 26:29 = 1:1.115 / 5th 31:30 = 1:0.968 / 6th 30:24 = 1:0.8
Final DriveShaft

Electrical & Electronics System

Battery12V – 18 Ah
StarterElectric

Chassis & Suspension

Frame TypeSteel tubing, closed double cradle with elastic kinematic engine mounting system to isolate vibrations.
Front SuspensionStandard fork, 45 mm, with radial caliper mounting bracket
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionSwingarm with double shock absorber with adjustable extension and spring preload with remote tank
Rear Suspension Travel4.7 inches / 120 mm
Trail38

Wheels & Brakes

Front Tire Size130/90 R16
Rear Wheel/Rim SizeAluminium alloy 5.50 x 16
Rear Tire Size180/65 R16
Front Brakes2 x320 mm stainless steel floating discs, Brembo radial calipers with 4 horizontally opposed pistons
Rear BrakesSingle282 mm stainless steel fixed disc, Brembo floating caliper with 2 parallel pistons

Dimension & Weights

Overall Length2445 mm / 90.2 in
Overall Width940 mm / 37.0 in
Overall Height1180 mm / 46.5 in
Seat Height29.1 inches / 740 mm
Wheelbase66.3 inches / 1685 mm
Ground Clearance165 mm / 6.4 in
Fuel Tank Capacity4.7 US gallons / 20.5 L

Features

  • 90 V-twin engine
  • Cardan final drive
  • 16 inch spoke wheels
  • Whitewall tires
  • Wraparound mudguards
  • Original complex surface headlight
  • Polyelliptical light with LED daylight running light (DRL)
  • 150 mm diameter circular instrumentation panel
  • Analog rev counter scale
  • Multifunction full-matrix suspended display
  • Bright chrome housing for instrumentation
  • 21 liter (5.5 gallon) fuel tank
  • Cruise control
  • Electric block with buttons
  • Bullhorn handlebar grip
  • Generous floorboards
  • Spoke wheels
  • Chrome fuel tank sides
  • Oversize saddle
  • Gem-shaped taillight
