The Moto Guzzi 850 T5 is a testament to the marque’s enduring commitment to performance and handling. This four-stroke, 90-degree V-twin powerplant is a masterclass in engine character, delivering a unique blend of torque and tractability that rewards rider input with a deep, resonant growl. On the road, the T5’s longitudinally-mounted engine and OHV valvetrain come together to create a riding experience that’s both effortless and exhilarating.
The 850 T5’s handling has been reworked to address the criticisms of its predecessor, with the addition of an 18-inch rear wheel and a fork brace that improves rake and stability. This thoughtful update has paid dividends, imbuing the bike with a newfound sense of poise and predictability.
The 850 T5 is a shining example of Moto Guzzi’s dedication to building motorcycles that are both beautiful and capable. With its rich, rasping engine note and agile handling, this bike is a true delight for any rider who appreciates the art of motorcycling.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Engine Capacity
51.5 cubic inches / 844 cc
Max Power
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Fuel Tank Capacity
6.0 US gallons / 23.0 L
Weight (Wet/Kerb)
507 lbs / 230 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 850 T5
Year
1983 –
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Displacement
51.5 cubic inches / 844 cc
Bore x Stroke
83 x 78 mm
Compression Ratio
9.5:1
Max Horsepower
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Engine Management System
2x 30mm Dell’Orto VHB carburetors
Cooling System
Air cooled
Performance
Top Speed
120.8 mph / 194.4 km/h
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Paioli telescopic air assisted
Rear Suspension
Dual Koni adjustable for preload.
Wheels & Brakes
Front Tire Size
110/90 V16
Rear Tire Size
130/90 V18
Front Brakes
2x 300mm discs 1 piston calipers
Rear Brakes
Single 242mm disc 1 piston caliper
Dimension & Weights
Fuel Tank Capacity
6.0 US gallons / 23.0 L
Wet (kerb/curb) Weight
507 lbs / 230 kg
Dry Weight
219 kg / 482.8 lbs
Features
90 V twin engine
Longitudinally mounted engine
OHV engine design
2 valves per cylinder
16-inch wheels (rear only, previously)
Revised to 18-inch rear wheel
Fork brace added
Forks kicked out in the yoke
Hydraulic steering damper
Same frame as the Guzzi Spada
Improved rake
Cured fork flex
Paoli air-shocks replaced with Konis
Revised suspension
Improved roadholding
4831lb (estimated) dry weight
16-inch front wheel
