The Moto Guzzi 850 T3 Windshield, a motorcycle that embodies the unique blend of European flair and American influence. Its 90-degree V-twin engine, longitudinally mounted and boasting 2 valves per cylinder, is a marvel of simplicity and efficiency. With 850cc of power, this transverse V-twin unit is both powerful and flexible, making it an ideal choice for long-distance touring.
The riding position, inspired by the Transcontinental, provides a comfortable and upright stance, while the large, dual seat and forward-set footboards add to the sense of adventure. However, it’s not just about looks – the ‘California’ has a lot to offer, including its unique engine character and handling.
As I rode the Moto Guzzi 850 T3 Windshield, I initially encountered some teething issues, but as the miles passed, I began to appreciate its true potential. The bike’s quirks and idiosyncrasies became endearing, and I found myself swept up in its charm. In the end, the Moto Guzzi 850 T3 Windshield proved to be a true gem, a motorcycle that rewards patience and persistence.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Engine Capacity
51.5 cubic inches / 844 cc
Max Power
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Fuel Tank Capacity
6.6 US gallons / 25.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 850 T3 Windshield
Year
1975
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Displacement
51.5 cubic inches / 844 cc
Bore x Stroke
83 x 78 mm
Compression Ratio
9.5:1
Max Horsepower
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Engine Management System
2x 30mm VHBT30 Dell’orto carburetors
Lubrication System
Gear driven oil pump with replaceable full flow oil filter
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telescopic forks
Rear Suspension
Dual shocks
Wheels & Brakes
Front Tire Size
3.50-18
Rear Tire Size
4.10-18
Front Brakes
2x 300mm discs 1 piston calipers
Rear Brakes
Single 242mm disc 1 piston caliper
Dimension & Weights
Wheelbase
58 inches / 1473.2 mm
Fuel Tank Capacity
6.6 US gallons / 25.0 L
Dry Weight
220 kg / 485 lbs
Features
Four stroke engine
90 V twin, longitudinally mounted
OHV (Overhead Valve) design
2 valves per cylinder
850cc transverse V-twin power unit
Powerful and flexible motor
Big wide dual seat
Rock hard seat despite implied promise of comfort
Forward-set footboards
Bars that put your hands almost in your lap
Pseudo-American styling
Longitudinally mounted engine
Wide handlebars
Low-profile riding position
Suitable for long-distance touring
High-performance engine
Dual-cylinder engine with 2 valves per cylinder
