The Moto Guzzi 850 T3 is a true gem of the 1970s motorcycle scene. This iconic machine boasts a four-stroke, 90-degree V-twin engine, longitudinally mounted for optimal power and balance. With a traditional OHV (overhead valve) design, each cylinder is fed by two valves, ensuring a rich, smooth power delivery that’s characteristic of the Guzzi breed.
Riding the 850 T3 is an experience like no other, with a silky-smooth power delivery and a soundtrack that’s equal parts melodic and menacing. As you twist the throttle, the V-twin engine comes alive, its harmonious thrum filling the air as you devour the roads ahead.
With its rich history and timeless design, the Moto Guzzi 850 T3 is a must-ride for any serious motorcycle enthusiast.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Engine Capacity
51.5 cubic inches / 844 cc
Max Power
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Fuel Tank Capacity
6.6 US gallons / 25.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 850 T3
Year
1977 –
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV, 2 valve per cylinder
Displacement
51.5 cubic inches / 844 cc
Bore x Stroke
83 x 78 mm
Compression Ratio
9.5:1
Max Horsepower
68.5 hp / 51.0 kW @ 7000 rpm
Max Torque
54.2 ft-lb / 7.5 kgf-m @ 5800 rpm
Engine Management System
2x 30mm VHBT30 Dell’orto carburetors
Lubrication System
Gear driven oil pump with replaceable full flow oil filter
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telescopic forks
Rear Suspension
Dual shocks
Wheels & Brakes
Front Tire Size
3.50-18
Rear Tire Size
4.10-18
Front Brakes
2x 300mm discs 1 piston calipers
Rear Brakes
Single 242mm disc 1 piston caliper
Dimension & Weights
Wheelbase
58 inches / 1473.2 mm
Fuel Tank Capacity
6.6 US gallons / 25.0 L
Dry Weight
220 kg / 485 lbs
Features
Four stroke engine
90 V twin configuration
Longitudinally mounted
OHV (Overhead Valve) design
2 valves per cylinder
