The 1977 Moto Guzzi 850 Le Mans Mark I embodies the essence of Italian motorcycle heritage, with a storied four-stroke V-twin engine that thunders to life beneath the rider. Longitudinally mounted and boasting a robust OHV pushrod setup with two valves per cylinder, this 90-degree twin unleashes a rich, sonorous soundtrack that harmonizes with the rhythm of the road.
A testament to Guzzi’s innovative design, the 850 Le Mans Mark I offers an unparalleled riding experience, with its longitudinally mounted engine placing the powerplant directly over the drive shaft for improved handling and balance.
As the engine’s full-throated growl becomes a symphony of power and precision, the rider is immersed in a world of raw, unbridled excitement, where the line between machine and rider dissolves in a blur of speed and adrenaline, and the road becomes an endless invitation to explore.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder
Engine Capacity
51.5 cubic inches / 844 cc
Max Power
80hp / 59.7 kW @ 7300 rpm
Max Torque
57.5 ft-lb / 79 nm
Fuel Tank Capacity
5.9 US gallons / 22.5 L
Weight (Wet/Kerb)
512 lbs / 232 kg
Seat Height
30.5 inches / 775 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 850 Le Mans MarkI
Year
1977
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder
Displacement
51.5 cubic inches / 844 cc
Bore x Stroke
83 x 78 mm
Compression Ratio
10.2:1
Max Horsepower
80hp / 59.7 kW @ 7300 rpm
Max Torque
57.5 ft-lb / 79 nm
Engine Management System
2x 36mm Dell’Orto carburetors
Lubrication System
Gear driven oil pump with replaceable full flow oil filter
