At the heart of the Moto Guzzi 850 Le Mans Mark II lies a potent 90-degree V-twin engine, its longitudinal configuration perfectly suited to the bike’s sleek, sport-oriented lines. Firing on a traditional OHV pushrod setup, each cylinder is fed by a pair of valves, carefully tuned to extract maximum power from its 850cc displacement.
This potent powerplant delivers a rich, throaty soundtrack that perfectly complements the bike’s aggressive styling, while its torquey, V-twin character ensures the Le Mans Mark II is as adept at carving up twisty mountain roads as it is at devouring long, sweeping highways.
As you delve into the saddle, the Guzzi’s engine comes alive, its smooth, linear power delivery making it a true delight to ride, as the bike’s agile handling and responsive steering invite you to push its limits even further.
Key Specifications
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder
Engine Capacity
51.5 cubic inches / 844 cc
Max Power
73 hp / 53.7 kW @ 7700 rpm
Max Torque
56.4 ft-lb / 76.4 nm
Fuel Tank Capacity
22.5 Litres / 4.8 gal
Seat Height
30 inches / 762 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 850 Le Mans Mark II
Year
1979 – 80
Engine
Engine Type
Four stroke, 90 V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder
Displacement
51.5 cubic inches / 844 cc
Bore x Stroke
83 x 78 mm
Compression Ratio
10.2:1
Max Horsepower
73 hp / 53.7 kW @ 7700 rpm
Max Torque
56.4 ft-lb / 76.4 nm
Engine Management System
2x 36mm Dell’Orto carburetors
Lubrication System
Gear driven oil pump with replaceable full flow oil filter
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Duplex cradle
Front Suspension
Oil damped telescopic fork
Rear Suspension
Swing arm with 3-pos preload
Wheels & Brakes
Front Tire Size
3.50 H18
Rear Tire Size
4.10 V18
Front Brakes
2x 310mm discs
Rear Brakes
Single 242mm disc
Dimension & Weights
Seat Height
30 inches / 762 mm
Wheelbase
58 inches / 1473 mm
Fuel Tank Capacity
22.5 Litres / 4.8 gal
Dry Weight
196 kg / 433 lbs
Features
Four-stroke engine
90-degree V-twin configuration
Longitudinally mounted engine
OHV (Overhead Valve) design
Pushrod-actuated valvetrain
2 valves per cylinder
