In the realm of two-wheeled engineering, few motorcycles have managed to carve out a niche as unique as the Moto Guzzi 254. This mighty mini-multi, produced between 1977 and 1981, boasted an air-cooled four-cylinder engine that weighed a mere 78 pounds, yet produced a claimed 28 BHP at 10,500 RPM.
The 254’s engine design was a marvel of its time, with a short-stroke configuration that allowed for effortless revving to its 11,800 RPM redline. This translated to a claimed top speed of 93 MPH, making it an enticing proposition for riders seeking a high-performance machine with a sporty edge.
But what truly set the 254 apart was its ability to deliver this performance in a package that was both visually stunning and remarkably agile. As noted by UK motorcycle journalist Brian Tarbox, the Moto Guzzi variant of the 254 boasted far more radical styling than its Benelli counterpart, making it a true head-turner on the road.
For those who crave a thrilling riding experience, the Moto Guzzi 254 is a must-ride, offering a perfect blend of style, substance, and sheer, unadulterated fun.
Key Specifications
Engine Type
Four stroke, transverse four cylinder, OHV, 2 valve per cylinder
Engine Capacity
14.1 cubic inches / 231 cc
Max Power
27.8 hp /19.7kW @ 10500 rpm
Fuel Tank Capacity
2.2 US gallons / 8.5 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Moto Guzzi 254
Year
1977 – 81
Engine
Engine Type
Four stroke, transverse four cylinder, OHV, 2 valve per cylinder
Displacement
14.1 cubic inches / 231 cc
Bore x Stroke
44 x 38 mm
Compression Ratio
11.5:1
Max Horsepower
27.8 hp /19.7kW @ 10500 rpm
Engine Management System
4x 18mm Dell’Orto VHB carbs
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Chassis & Suspension
Front Suspension
Telescopic hydraulic forks
Rear Suspension
Swinging fork and shock absorbers
Wheels & Brakes
Front Tire Size
2.75 -18
Rear Tire Size
3.00 -18
Front Brakes
Single disc
Rear Brakes
Drum
Dimension & Weights
Wheelbase
1270 mm /
Fuel Tank Capacity
2.2 US gallons / 8.5 L
Dry Weight
126.5 kg /275.6 lbs
Features
Ultra-sleek Euro styling
Air-cooled engine
Weight of 78 pounds for the engine alone
Four 18 mm Dell Orto carbs
4-into-2 exhaust system
Five speed transmission
Chain final drive
Short-stroke engine (44 mm x 38 mm)
11,800 RPM redline
Claimed 28 BHP at 10,500 RPM
Claimed top speed of 93 MPH
Aluminum and plastic construction to minimize weight
Weight of 278 lbs
2.2 US gallon (8.5 L) fuel tank
39 MPG average fuel economy
Five-cylinder engine design
1047cc engine displacement (Benelli version)
