KTM RC8R 1190Red BullLimited Edition (2010)

KTM RC8R 1190Red BullLimited Edition (2010)

The latest iteration of KTM’s 1190 RC8 R has just been unveiled, and it’s a beast of a bike. The 2010 KTM RC8R Red Bull Limited Edition superbike replica is a track-focused machine that embodies the essence of high-performance riding. With a 75° V-twin engine, the RC8R packs a punch, boasting an impressive 180hp when paired with the optional club race kit.

The bike’s engine has undergone significant upgrades, including super light pistons, increased compression ratio, reworked combustion chamber, and adjustable camshafts. The result is a responsive and agile power delivery that is sure to thrill any track day enthusiast.

But the RC8R is not just about raw power – its chassis has also been revised with a race-spec suspension, adjustable pegs, shifter, subframe, and ride height, making it a highly capable handling machine.

This limited edition model is a true replica of the Red Bull livery worn by Stefan Nebel in the German Superbike Championship, and it’s a testament to KTM’s commitment to creating high-performance motorcycles that can hold their own on the track. With only 100 units available, the KTM 1190 RC8R Red Bull Limited Edition is a rare opportunity for riders to experience the ultimate in track-focused riding.

Key Specifications

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity73.0 cubic inches / 1195 cc
Max Power167.6 hp / 122.4 kW) @ 10250 rpm
Max Torque12.5 kgf-m / 90.7 ft.lbs @ 8000 rpm
Fuel Tank Capacity16.5 Litres / 3.5 gal
Seat Height805 mm / 825 mm
KTM RC8R 1190Red BullLimited Edition (2010)

All Specifications

Make & Model

ModelKTM RC8R 1190Red BullLimited Edition
Year2010

Engine

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement73.0 cubic inches / 1195 cc
Bore x Stroke105 x 69 mm
Compression Ratio13.5 :1
Max Horsepower167.6 hp / 122.4 kW) @ 10250 rpm
Max Torque12.5 kgf-m / 90.7 ft.lbs @ 8000 rpm
Cooling SystemLiquid cooling

Performance

Top Speed271.4 km/h

Transmission

ClutchWet multi-disc clutch, operated hydraulically
Gearbox6 Speed
Final Drive17:37

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeChromium-Molybdenum trellis frame, powder-coatedSubframe Aluminium
Front Suspension43mm WP Upside down adjustable
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionWP shock, fully adjustable
Rear Suspension Travel4.9 inches / 125 mm
Trail97 mm / 3.82 in

Wheels & Brakes

Front Tire Size120/70 ZR17
Rear Tire Size190/55 ZR17
Front Brakes2x 320mm discs 4 piston calipers
Rear BrakesSingle 240mm disc

Dimension & Weights

Seat Height805 mm / 825 mm
Ground Clearance110 mm / 4.3 in
Fuel Tank Capacity16.5 Litres / 3.5 gal
Dry Weight182 kg / 405.23 lb (no fuel)

Features

  • Four stroke, 75V-twin cylinder engine
  • DOHC, 4 valves per cylinder
  • 1195cc displacement
  • 170hp power output
  • 180hp power output with optional club race kit
  • LC8 two-cylinder engine
  • Enlarged oil cooler
  • Optimised gears
  • 7.5kg lightweight steel trellis frame
  • Modified chassis geometry
  • Caster raised by 6mm
  • Wheel base shortened
  • WP suspension 43mm upsidedown fork
  • TiAlNi-coated WP shock absorber
  • Forged Marchesini light alloy wheels
  • Radially-mounted Brembo four-piston monoblock brake callipers
  • Reinforced 320mm brake discs
  • Limited edition number plate
  • Special edition body work
  • Adjustable pegs
  • Adjustable shifter
