KTM RC8R 1190 (2014)

KTM RC8R 1190 (2014)

The KTM RC8R 1190 is a masterclass in motorcycle design, where engineers have crafted a 75-degree V-twin powerhouse that defies convention.

This liquid-cooled beast boasts an impressive 1,195cc displacement, its V-twin configuration delivering a unique blend of character and ferocity. As you twist the throttle, the 1190 RC8R’s engine sings a sweet melody of power, its DOHC setup and four valves per cylinder ensuring a seamless delivery of torque.

Behind the handlebars, the RC8R’s ergonomics are a revelation, with adjustable settings for footrests, foot levers, seat, and hand levers allowing riders to tailor the bike to their individual needs. The chassis is equally impressive, its progressive linkage providing a refined responsiveness that belies its ability to withstand peak loads.

With its Brembo-equipped brake system and intricately crafted light alloy swingarm, the RC8R is a force to be reckoned with on the road, its exceptional traction and handling capabilities making it a true thoroughbred of the streets.

Key Specifications

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity73.0 cubic inches / 1195 cc
Max Power129 kw / 175 hp
Max Torque93.6 ft-lb / 127 nm
Fuel Tank Capacity16.5 Litres / 4.3 gal
Seat Height31.69 inches / 805 mm
KTM RC8R 1190 (2014)

All Specifications

Make & Model

ModelKTM RC8R 1190
Year2014

Engine

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement73.0 cubic inches / 1195 cc
Bore x Stroke105 x 69 mm
Compression Ratio13.5 :1
Max Horsepower129 kw / 175 hp
Max Torque93.6 ft-lb / 127 nm
Engine Management SystemKeihin EFI throttle body 52 mm
Lubrication SystemPressure lubrication with 3 Eaton pumps
Cooling SystemLiquid cooling

Performance

Top Speed271.4 km/h

Transmission

ClutchWet, multiple discs, hydraulic operated
Gearbox6 Speed claw shifted
Final DriveChain 5/8 x 5/16″ X Ring

Electrical & Electronics System

Chassis & Suspension

Frame TypeChromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar
Front Suspension43mm WP Upside down adjustable
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionWP shock, fully adjustable
Rear Suspension Travel4.9 inches / 125 mm
Trail97 mm / 3.82 in

Wheels & Brakes

Front Tire Size120/70 ZR17
Rear Tire Size190/55 ZR17
Front Brakes2x 320mm discs 4 piston calipers
Rear BrakesSingle 240mm disc

Dimension & Weights

Seat Height31.69 inches / 805 mm
Wheelbase56.1 inches / 1425 mm
Ground Clearance110 mm / 4.3 in
Fuel Tank Capacity16.5 Litres / 4.3 gal
Dry Weight186.0 kg / 410.1 lbs

Features

  • Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder engine
  • 1,195 cm displacement
  • Liquid-cooled engine
  • Electric starter
  • Two adjustable footrest heights
  • Two adjustable foot lever operating angles and lever lengths
  • Two adjustable seat heights
  • Variable hand lever
  • Two adjustable handlebar heights and angles
  • Linkage with adjustable swingarm position
  • Brembo brake components
  • Radially-mounted, four-piston brake callipers
  • Semi-floating brake discs
  • Adjustable swingarm position
  • High-strength, chrome-molybdenum steel frame
  • High-quality, upside-down WP Suspension fork
  • Adjustable fork preload, compression, and rebound damping
  • WP shock absorber with independent compression and rebound damping adjustment
