The highly anticipated 2022 KTM RC range is finally here, bringing the raw power and precision of KTM’s racing DNA to the streets. At the heart of this sports bike is a four-stroke, single-cylinder engine, boasting a DOHC configuration with finger followers and 4 valves that deliver a thrilling riding experience.
The new KTM RC range has undergone a radical redesign, inspired by Grand Prix-winning machines. Every panel has been reimagined to create a sporty, aggressive aesthetic, complete with two fresh colorways that scream performance. Computational fluid dynamics have been used to optimize aerodynamics, ensuring the bike cuts through the air with ease, while also providing improved wind and weather protection for the rider.
But it’s not just about looks – the new KTM RC range has been engineered to deliver exceptional handling and control. Ergonomics have been meticulously refined to enable riders to move freely and naturally, with a narrow knee area and a two-part cockpit that provides a comfortable and commanding riding position. With its lightweight steel trellis sub-frame and revised bodywork, the KTM RC 125 is ready to unleash its full potential on any road.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC with finger followers, 4 Valves
Engine Capacity
7.6 cubic inches / 124.7 cc
Max Power
20 hp / 15 kW
Max Torque
8.85 ft-lb / 12 nm
Fuel Tank Capacity
13.7 Liters / 3.6 US gal
Seat Height
32.4 inches / 824 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM RC 125
Year
2022
Engine
Engine Type
Four stroke, single cylinder, DOHC with finger followers, 4 Valves
Displacement
7.6 cubic inches / 124.7 cc
Bore x Stroke
58 x 47.2 mm
Max Horsepower
20 hp / 15 kW
Max Torque
8.85 ft-lb / 12 nm
Engine Management System
Bosch Injection
Lubrication System
Wet sump
Cooling System
Liquid Cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch / mechanically operated
Gearbox
6 Speed
Final Drive
520 X-Ring
Electrical & Electronics System
Starter
Electric
ABS
Bosch 9.1 MB Two Channel ABS (Supermoto ABS)
Chassis & Suspension
Frame Type
Steel trellis frame, powder coated
Front Suspension
USD WP APEX 43
Rear Suspension
WP APEX – Monoshock
Rear Suspension Travel
5.9 inches / 150 mm
Trail
66.5
Wheels & Brakes
Front Tire Size
110/70 -17
Rear Tire Size
150/60 17
Front Brakes
Single320 mm disc, 4 piston radial fixed calliper
Rear Brakes
Single230 mm disc, single-piston floating calliper
ABS
Bosch 9.1 MB Two Channel ABS (Supermoto ABS)
Dimension & Weights
Seat Height
32.4 inches / 824 mm
Ground Clearance
158 mm / 6.2 in
Fuel Tank Capacity
13.7 Liters / 3.6 US gal
Dry Weight
147 kg / 324 lbs
Features
Four stroke, single cylinder engine
DOHC with finger followers
4 Valves
Grand Prix-inspired design
Redesigned panels for improved aerodynamics
Computational fluid dynamics design process
Enhanced wind and weather protection
Improved heat management
Steel trellis sub-frame
Ergonomically developed knee area
Two-part cockpit and windscreen holder
Cast aluminum upper part
Composite lower part
Larger fuel tank
Easily removable bodywork
New wheel design with 3.4 kg unsprung weight saving
ByBre braking system with 960 gram weight saving
1.5 kg weight saving on the frame
Adjustable open cartridge WP APEX upside-down front forks
30 clicks of compression adjustment
30 clicks of rebound adjustment
