The KTM RC 125 is the perfect recipe for young riders and racing enthusiasts, packing a potent punch in a lightweight, compact package. Its state-of-the-art, liquid-cooled engine delivers a respectable 15 hp (11 kW) and 12 Nm of torque, making it the sportiest option out there for A1 riders.
Thanks to its ingenious intake design and meticulous fuel injection system, the KTM RC 125 is ready to leave the rest of the city traffic behind at the twist of a wrist, making every ride a thrilling experience.
On the handling front, the RC 125 boasts a 66.5 degree steering-head angle, identical to its bigger brothers, ensuring quick, agile and playful handling on the streets or racetrack. The bike’s WP suspension components and forged aluminum triple clamps complete the package, guaranteeing a pure supersport racing feeling.
With its premium exhaust system meeting the latest Euro 4 emission restrictions and sound regulations, the KTM RC 125 is a machine that delivers smooth power with style, and is sure to leave a lasting impression on any rider. The KTM RC 125 is the ultimate entry-level machine for those who dare to dream big.
Key Specifications
Engine Type
Four stroke, single cylinder. DOHC with finger followers, 4 Valve
Engine Capacity
7.6 cubic inches / 124.7 cc
Max Power
15.hp / 10.9 kW @ 9500 rpm
Max Torque
11.8 Nm /8 lbft@ 8000 rpm
Fuel Tank Capacity
10 Liters / 2.6 US gal
Seat Height
32.3 inches / 820 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM RC 125
Year
2020 – 2021
Engine
Engine Type
Four stroke, single cylinder. DOHC with finger followers, 4 Valve
Displacement
7.6 cubic inches / 124.7 cc
Bore x Stroke
58 x 47.2 mm
Compression Ratio
14.5:1
Max Horsepower
15.hp / 10.9 kW @ 9500 rpm
Max Torque
11.8 Nm /8 lbft@ 8000 rpm
Engine Management System
Bosch Injection
Lubrication System
Forced oil lubrication with 2 Eaton pumps
Cooling System
Liquid Cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch / mechanically operated
Gearbox
6 Speed
Final Drive
Chain5/8 x 1/4 X‑Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Tubular space frame made from steel, powder-coated
Front Suspension
WP Suspension Up Side Down
Rear Suspension
WP Monoshock
Rear Suspension Travel
5.9 inches / 150 mm
Rake
65
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Tire Size
110/70 -17
Rear Tire Size
150/60 17
Front Brakes
Single300mm disc
Rear Brakes
Single230mm disc
Dimension & Weights
Seat Height
32.3 inches / 820 mm
Wheelbase
47.6 inches / 1210 mm
Ground Clearance
179 mm / 7.0 in
Fuel Tank Capacity
10 Liters / 2.6 US gal
Dry Weight
135 kg / 297.6 lbs
Features
Four stroke, single cylinder engine
DOHC with finger followers, 4 Valve
15 hp (11 kW) of power
12 Nm of torque
Liquid-cooled engine
Electronic fuel injection
EURO 4 compliant exhaust
Lightweight and compact engine design
Good fuel economy
66.5 degree steering-head angle
WP suspension components
Forged aluminum triple clamps
Clip on handlebars
17 inch cast alloy wheels
110 mm wide front wheel
150 mm wide rear wheel
Premium rubber tires
High-quality upside-down fork from WP Suspension
43 mm outer tube diameter fork
