The KTM Freeride 350 is an off-road thrill-seeker’s dream come true. This lightweight, 4-stroke single-cylinder engine delivers a smooth, torque-rich ride that’s perfect for navigating technical trails and back roads. With a DOHC design and 4 valves per cylinder, the engine’s punchy power delivery is complemented by a range of optimized features, including a revised gear ratio and final gearing for improved fuel efficiency and reduced emissions.
The Freeride 350’s compact design receives a number of upgrades for the 2014 model year, including a modified exhaust camshaft and automatic decompression system for improved starting performance. The result is a ride that’s both exhilarating and effortless, with a weight of just 114 kg making it an absolute blast to handle.
Whether you’re a seasoned off-road enthusiast or just looking to dip your toes into the world of adventure riding, the KTM Freeride 350 is an unbeatable choice for anyone who demands a thrilling ride without the need for high-tech gadgetry or complicated ergonomics.
Key Specifications
Engine Type
Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder,
Engine Capacity
21.3 cubic inches / 349 cc
Fuel Tank Capacity
1.22 US gallons / 5.5 L
Seat Height
35.2 inches / 915 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM Freeride 350
Year
2014 – 2015
Engine
Engine Type
Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder,
Displacement
21.3 cubic inches / 349 cc
Bore x Stroke
88 X 57.5 mm
Compression Ratio
12.3:1
Engine Management System
Keihin EFI, flow restrictor 42 mm
Cooling System
Liquid Cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch, Brembo hydraulics
Gearbox
6 Speed, claw shifted
Primary Drive Ratio
24:73
Final Drive
Chain 5/8 x 1/4″ X Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Perimeter steel-aluminium composite frame
Front Suspension
WP Suspension4357 MXMA
Front Suspension Travel
9.8 inches / 250 mm
Rear Suspension
WP-PDS shock absorber,
Rear Suspension Travel
10.2 inches / 280 mm
Trail
67
Wheels & Brakes
Front Tire Size
80/100-21
Rear Tire Size
110/90-19
Front Brakes
Single 260mm disc 2 piston caliper
Rear Brakes
Single 210mm disc 1 piston caliper
Dimension & Weights
Seat Height
35.2 inches / 915 mm
Wheelbase
56.2 inches / 1428 mm
Fuel Tank Capacity
1.22 US gallons / 5.5 L
Dry Weight
101 kg / 222.7 lbs
Features
Four stroke, single cylinder engine
DOHC with finger followers, 4 Valve per cylinder
Closed loop lambda control with Keihin engine management system
Electronic fuel injection and 42mm throttle body
Two catalytic converters for efficient exhaust gas treatment
State-of-the-art engine management system
High fuel efficiency for an off-road bike
Optional map select switch for additional engine response characteristics
Six-speed transmission with shorter gear ratios in lower five gears
Taller sixth gear for relaxed engine speed levels on back roads
Final gearing made taller with 12-tooth chain sprocket
Lightweight CSS clutch
Revised Formula hydraulic system
Optimised engine for pleasant torque response instead of maximum power
Compact design with modified exhaust camshaft and automatic decompression
Four steel valves with reinforced spring retainers
Electric starter with reinforced freewheel assembly
Protected placement of the electric starter
Improved seal with redesigned coolant pump cover and new gasket
Liquid-cooled engine design
Geared intermediate shaft for driving camshafts and coolant pump
Balancer shaft for reduced vibrations
Overhead camshafts with DLC coated finger followers
Spark-ignition engine with liquid-cooling
