The KTM 990 Supermoto is a razor-sharp, adrenaline-fueled machine that embodies the raw excitement of Supermoto. Its revised LC8 engine, now displacing 999cc, unleashes an astonishing 85kW at 9000rpm, paired with a responsive Keihin engine management system and fuel injection.
Weighing a mere 58kg, this powerhouse is nestled within a lightweight chromium-molybdenum frame, boasting an impressive 11kg overall weight reduction. The short 1,510mm wheelbase and 64.6-degree Steering Head Angle further amplify its agility and precision.
But what truly sets the 990 Supermoto apart is its uncanny ability to seamlessly transition from the asphalt to the dirt, making it an off-road companion like no other. With WP suspension and Brembo brakes at its disposal, this Austrian thoroughbred is ready to take on the most challenging terrain with unbridled ferocity, leaving all else in its dust.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 999.8 cc
Max Power
114.hp / 83.2 kW) @ 4000 rpm
Max Torque
97.Nm / / 71.5 ft/lb @ 7000 rpm
Fuel Tank Capacity
15 Litres / 3.9 gal
Seat Height
34.45 inches / 875 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 990 Supermoto
Year
2010
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 999.8 cc
Bore x Stroke
101 x 62.4mm
Compression Ratio
11.5:1
Max Horsepower
114.hp / 83.2 kW) @ 4000 rpm
Max Torque
97.Nm / / 71.5 ft/lb @ 7000 rpm
Engine Management System
Electronic fuel injection / electric
Lubrication System
Dry-sump lubrication with 2 rotor pumps
Cooling System
Liquid cooling
Exhaust
2 x Premium steel with three-way-catalyser
Performance
Top Speed
229.8 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch, operated hydraulically
Gearbox
6 Speed
Final Drive
Chain.
Electrical & Electronics System
Battery
12 V/11.2 Ah
Starter
Electric
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
48mm WP USD adjustable
Front Suspension Travel
6.3 inches / 160 mm
Rear Suspension
WP shock, fully adjustable
Rear Suspension Travel
7.1 inches / 180 mm
Rake
24.4
Trail
109 mm / 4.3 in
Wheels & Brakes
Front Tire Size
120/70 ZR17
Rear Tire Size
180/55 ZR17
Front Brakes
2x 305mm discs 4 piston calipers
Rear Brakes
Single 240mm disc 2 piston caliper
Dimension & Weights
Seat Height
34.45 inches / 875 mm
Wheelbase
59.3 inches / 1505 mm
Ground Clearance
195 mm / 7.7 in
Fuel Tank Capacity
15 Litres / 3.9 gal
Dry Weight
192 kg / 423 lbs
Features
Four stroke, 75V-twin cylinder engine
DOHC, 4 valves per cylinder
LC8 engine
58 kg weight
Chromium-molybdenum frame
11 kg weight
Short wheelbase (1,510 mm)
64.6 degree Steering Head Angle
999cc LC8 engine
85 kW at 9000 rpm
97 Nm at 7000 rpm
Keihin engine management system
Fuel injection
Bigger cylinder capacity
Aluminum subframe
WP suspensions
Brembo brakes
942cc unit developed 70.5 kW (96.55 HP) @ 8000 RPM
94.00 Nm @ 6500 RPM
