KTM 990 Super Duke (2006)

KTM 990 Super Duke (2006)

The KTM 990 Super Duke is a riding experience like no other. Its 75-degree V-twin engine, with four valves per cylinder and DOHC, unleashes a torrent of power and torque, making it a thrill to ride. The Super Duke devours curves with precision, agility, and a hint of radicality, leaving the landscape a blur as you crave more.

As you immerse yourself in the ride, the centrifugal force becomes intoxicating, and the connection to the road is palpable. The minimalist bodywork and spartan dash only add to the bike’s raw, unadulterated nature. With 118 horsepower at your disposal, the Super Duke is an addicting passion that will leave you wanting more.

Key Specifications

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity60.9 cubic inches / 999.8 cc
Max Power88 kw / 120 hp
Max Torque100 Nm @ 7000 rpm
Fuel Tank Capacity18.5 Litres / 4.8 gal
Seat Height33.6 inches / 855 mm
KTM 990 Super Duke (2006)

All Specifications

Make & Model

ModelKTM 990 Super Duke
Year2006

Engine

Engine TypeFour stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement60.9 cubic inches / 999.8 cc
Bore x Stroke101 x 62.4mm
Compression Ratio11.5:1
Max Horsepower88 kw / 120 hp
Max Torque100 Nm @ 7000 rpm
Engine Management SystemElectronic fuel injection / electric
Lubrication SystemDry-sump lubrication with 2 rotor pumps
Cooling SystemLiquid cooling,
Exhaust2 x Premium steel with three-way-catalyser

Performance

Top Speedn/a

Transmission

ClutchWet multi-disc clutch, operated hydraulically
Gearbox6 Speed
Final DriveChain, X-Ring 5/8 x 5/16″

Electrical & Electronics System

Battery12 V/11.2 Ah
StarterElectric

Chassis & Suspension

Frame TypeChromium-Molybdenum trellis frame, powder-coated Subframe AluminiumHandlebar Aluminium 28/22 mm (1.89″), tapered
Front Suspension48mm WP Upside down adjustable
Front Suspension Travel5.3 inches / 135 mm
Rear SuspensionWP shock, fully adjustable
Rear Suspension Travel6.3 inches / 160 mm
Rake24
Trail103mm / 4.0 in

Wheels & Brakes

Front Tire Size120/70 ZR17
Rear Tire Size180/55 ZR17
Front Brakes2x 320mm discs 4 piston calipers
Rear BrakesSingle 240mm disc 1 piston caliper

Dimension & Weights

Seat Height33.6 inches / 855 mm
Wheelbase56.6 inches / 1438 mm
Ground Clearance165 mm / 6.4 in
Fuel Tank Capacity18.5 Litres / 4.8 gal
Dry Weight186 kg / 410 lbs

Features

  • 75V-twin cylinder engine
  • Four stroke
  • DOHC
  • 4 valves per cylinder
  • 990cc displacement
  • 118 horsepower
  • Radial-mount front Brembos
  • Tubular handlebar
  • Lightweight, 405 pounds dry weight
  • Ultra-precise handling
  • Radical and agile cornering
  • High cornering speeds
  • Low dry weight for twin-cylinder standards
  • High feedback from tires
  • Easy wheelies and stoppies
  • Fuel-injected engine
  • Multifunction display
  • Dual mufflers
  • Minimalist bodywork
  • Spartan dash
