The KTM 990 Adventure S is a behemoth of a motorcycle, bred for the grueling demands of the Paris Dakar Rally. Its LC8 V-twin engine, a true marvel of engineering, pumps out a staggering 98.00 HP at 8000rpm and 95.00 Nm of torque at 6000rpm.
This potent powerplant is paired with a robust chassis, designed to tackle the toughest off-road terrain with ease. And yet, the 990 Adventure S is just as at home on the pavement, its riding dynamics honed to deliver a smooth, responsive experience.
Whether you’re carving through twisties or plowing through mud, the 990 Adventure S is the ultimate adventure motorcycle. Its impressive capabilities, combined with its stylish design, make it the perfect companion for any journey. And with its reputation for reliability and performance, it’s clear that the KTM 990 Adventure S is the standard by which all others are measured.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 999.8 cc
Max Power
96.5 hp / 70.5 kW @ 8500 rpm
Max Torque
70.1 ft-lb / 95 nm
Fuel Tank Capacity
22 Litres / 5.8 gal
Seat Height
36. inches / 915 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 990 Adventure S
Year
2006
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 999.8 cc
Bore x Stroke
101 x 62.4mm
Compression Ratio
11.5;1
Max Horsepower
96.5 hp / 70.5 kW @ 8500 rpm
Max Torque
70.1 ft-lb / 95 nm
Engine Management System
Keihin Electronic Fuel Injection EMS
Lubrication System
Pressure lubrication with 2 Eaton pumps
Cooling System
Liquid cooling
Exhaust
Twin stainless steel silencer with regulated catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet Multi-disc hydraulically operated,
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 5/16″
Electrical & Electronics System
Battery
12 V/11.2 Ah
Starter
Electric
Chassis & Suspension
Frame Type
Tubular cromoly spaced frame. powered coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
9.8 inches / 250 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload
Rear Suspension Travel
10.0 inches / 255 mm
Rake
26.6
Trail
119 mm / 4.68 in
Handlebar
Aluminium, tapered, 28/22 mm
Wheels & Brakes
Front Wheel/Rim Size
2.15 x 21”;
Front Tire Size
90/90 -21
Rear Wheel/Rim Size
4.25 x 18”
Rear Tire Size
150/70 -R18
Front Brakes
2x 300mm Brembo discs 2 piston calipers
Rear Brakes
Single 240mm Brembo disc 1 piston caliper
Dimension & Weights
Seat Height
36. inches / 915 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
316 mm / 12.4 in
Fuel Tank Capacity
22 Litres / 5.8 gal
Dry Weight
199 kg / 438.7 lbs
Features
Four-stroke engine
75V-twin cylinder
DOHC
4 valves per cylinder
990 Adventure model
Reliability
Performance
Style
LC8 V-twin engine
950cc engine displacement
98.00 HP @ 8000rpm
95.00 Nm @ 6000rpm
Fuel injection
Regulated catalytic converter
Euro III regulations
ABS braking system
999cc engine displacement (2007 and later)
Liquid-cooled engine
90 degree V-twin engine configuration
