The KTM 990 Adventure R Dakar is a testament to the Austrian manufacturer’s rich history in endurance racing. The 999cc V-75 Twin engine, a development of the powerplant used in the Adventure R, unleashes 115 bhp, ensuring a thrilling riding experience.
Linked to a 6-speed transmission and featuring a hydraulically operated wet multi-disc clutch, the engine provides seamless acceleration and control.
The ride is further enhanced by Bosch ABS and WP-PDS suspension, offering 210mm of travel and ensuring a smooth ride even on the most challenging terrain.
A true Dakar tribute, the 990 Adventure R Dakar is designed for those who crave adventure and are willing to push the limits. It is the ultimate tool for the modern-day explorer, capable of tackling the toughest off-road challenges with ease and precision.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 999.8 cc
Max Power
116 hp / 85 kW @ 9000 pm
Max Torque
73.8 ft-lb / 100 nm
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Seat Height
35.6 inches / 905 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 990 Adventure R Dakar
Year
2011
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 999.8 cc
Bore x Stroke
101 x 62.4mm
Compression Ratio
11.5;1
Max Horsepower
116 hp / 85 kW @ 9000 pm
Max Torque
73.8 ft-lb / 100 nm
Engine Management System
Keihin Electronic Fuel Injection EMS
Cooling System
Liquid cooling
Exhaust
Twin stainless steel silencer with regulated catalytic converter
Performance
Top Speed
210.7 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet Multi-disc hydraulically operated,
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 5/16″
Electrical & Electronics System
Battery
12 V/11.2 Ah
Starter
Electric
Chassis & Suspension
Frame Type
Tubular cromoly spaced frame. powered coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
9.7 inches / 248 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload
Rear Suspension Travel
9.7 inches / 248 mm
Rake
26.6
Trail
119 mm / 4.68 in
Handlebar
Aluminium, tapered, 28/22 mm
Wheels & Brakes
Front Wheel/Rim Size
2.15 x 21”;
Front Tire Size
90/90 -21
Rear Wheel/Rim Size
4.25 x 18”
Rear Tire Size
150/70 -R18
Front Brakes
2x 300mm Brembo discs 2 piston calipers
Rear Brakes
Single 240mm Brembo disc 1 piston caliper
Dimension & Weights
Seat Height
35.6 inches / 905 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
301 mm / 11.85 in
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Dry Weight
207 kg / 456.34 lbs
Features
999cc V-75 Twin engine
115 bhp
6 speed transmission
Hydraulically operated, wet multi-disc clutch
Bosch ABS
Adventure-based suspensions with 210 mm of travel
Linkageless WP-PDS suspension
Foldaway knob for adjusting spring preload
Orange powder-coated crash bars
Velour-upholstered seat
5.3 gallons of fuel capacity
Split fuel tank
Pirelli universal tires
Bosch/Brembo ABS
527 lbs. wet weight
42 lbs. lighter than BMW R1200GS
