The KTM 990 Adventure R is a high-performance off-road machine that sets a new standard for adventure touring motorcycles. Its 999cc, 75-degree V-twin engine produces a remarkable 113.31 horsepower at 8,750 rpm and 100 Nm of torque at 6,750 rpm, delivering a thrilling riding experience.
The R model’s 2-kilogram weight reduction and 20mm higher seat height make it ideal for experienced riders who crave a more aggressive riding style. Its lighter weight and increased power output make it perfect for tackling challenging terrain, while its distinctive look sets it apart from its standard counterpart.
The KTM 990 Adventure R is the culmination of KTMs engineering expertise, offering a potent blend of power, agility, and off-road capability. Whether you’re carving through twisty roads or conquering rugged trails, this bike is sure to deliver an exhilarating experience that will leave you wanting more.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 999.8 cc
Max Power
113.3 hp / 84.5 kW @ 8750 rpm
Max Torque
73.8 ft-lb / 100 nm
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Seat Height
36. inches / 915 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 990 Adventure R
Year
2010
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 999.8 cc
Bore x Stroke
101 x 62.4mm
Compression Ratio
11.5;1
Max Horsepower
113.3 hp / 84.5 kW @ 8750 rpm
Max Torque
73.8 ft-lb / 100 nm
Engine Management System
Keihin Electronic Fuel Injection EMS
Cooling System
Liquid cooling
Exhaust
Twin stainless steel silencer with regulated catalytic converter
Performance
Top Speed
210.7 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet Multi-disc hydraulically operated,
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 5/16″
Electrical & Electronics System
Battery
12 V/11.2 Ah
Starter
Electric
Chassis & Suspension
Frame Type
Tubular cromoly spaced frame. powered coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
9.7 inches / 248 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload
Rear Suspension Travel
9.7 inches / 248 mm
Rake
26.6
Trail
119 mm / 4.68 in
Handlebar
Aluminium, tapered, 28/22 mm
Wheels & Brakes
Front Wheel/Rim Size
2.15 x 21
Front Tire Size
90/90 -21
Rear Wheel/Rim Size
4.25 x 18
Rear Tire Size
150/70 -R18
Front Brakes
2x 300mm Brembo discs 2 piston calipers
Rear Brakes
Single 240mm Brembo disc 1 piston caliper
Dimension & Weights
Seat Height
36. inches / 915 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
316 mm / 12.4 in
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Dry Weight
207 kg / 456.34 lbs
Features
999cc, twin-cylinder, four-stroke, V 75-degree engine
104.6 hp at 8,250 rpm
100 Nm at 6,750 rpm
113.31 hp at 8,750 rpm
100 Nm at 6,750 rpm (R model)
115bhp from the Superduke-derived engine (R model)
18bhp more powerful than the older machine (R model)
55mm extra suspension travel
DOHC
4 valves per cylinder
Four stroke
75V-twin cylinder engine
Standard model is 2 kilograms heavier than the R model
R model features an almost 2 inches higher seat
Gel seat is available as an optional extra
ABS fitted on the standard model but not available on the R model
Higher seat height can make the bike awkward at a standstill
