The KTM 990 Adventure R is a powerhouse of a motorcycle, boasting a 999cc, twin-cylinder engine that delivers a staggering 113.31 horsepower at 8,750 rpm and 100 Nm of torque at 6,750 rpm. Building on the success of the standard 990 Adventure, the R model is a more potent and agile machine, weighing in at a mere 2 kilograms less than its stablemate.
Its engine character is a perfect blend of power and control, making it ideal for both on- and off-road excursions. The KTM 990 Adventure R is designed to bring riding excitement to a whole new level, with its higher seat and distinctive styling cues making it a thrill-seeker’s dream come true.
For those who crave even more performance, the R model’s 55mm extra suspension travel gives it a commanding advantage off the beaten track. But it’s not just about raw power – the KTM 990 Adventure R is also a masterclass in balance and control, making it an absolute joy to ride on a variety of terrain. In short, the KTM 990 Adventure R is a force to be reckoned with, and a truly unforgettable riding experience.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 999.8 cc
Max Power
113.3 hp / 84.5 kW @ 8750 rpm
Max Torque
73.8 ft-lb / 100 nm
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Seat Height
36. inches / 915 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 990 Adventure R
Year
2009
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 999.8 cc
Bore x Stroke
101 x 62.4mm
Compression Ratio
11.5;1
Max Horsepower
113.3 hp / 84.5 kW @ 8750 rpm
Max Torque
73.8 ft-lb / 100 nm
Engine Management System
Keihin Electronic Fuel Injection EMS
Lubrication System
Pressure lubrication with 2 Eaton pumps
Cooling System
Liquid cooling
Exhaust
Twin stainless steel silencer with regulated catalytic converter
Performance
Top Speed
210.7 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet Multi-disc hydraulically operated,
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 5/16″
Electrical & Electronics System
Battery
12 V/11.2 Ah
Starter
Electric
Chassis & Suspension
Frame Type
Tubular cromoly spaced frame. powered coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
9.7 inches / 248 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload
Rear Suspension Travel
9.7 inches / 248 mm
Rake
26.6
Trail
119 mm / 4.68 in
Handlebar
Aluminium, tapered, 28/22 mm
Wheels & Brakes
Front Wheel/Rim Size
2.15 x 21”;
Front Tire Size
90/90 -21
Rear Wheel/Rim Size
4.25 x 18”
Rear Tire Size
150/70 -R18
Front Brakes
2x 300mm Brembo discs 2 piston calipers
Rear Brakes
Single 240mm Brembo disc 1 piston caliper
Dimension & Weights
Seat Height
36. inches / 915 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
316 mm / 12.4 in
Fuel Tank Capacity
19.5 Litres / 5.1 gal
Dry Weight
207 kg / 456.34 lbs
Features
999cc, twin-cylinder, four-stroke, V 75-degree engine
104.6 hp at 8,250 rpm and 100 Nm at 6,750 rpm on the standard model
113.31 hp at 8,750 rpm and 100 Nm at 6,750 rpm on the R model
2 kilograms lighter on the R model
2 inches higher seat on the R model
Four-stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
18bhp more powerful than the 990 Adventure S
115bhp from the Superduke-derived engine
55mm extra suspension travel on the R model
Smoother-running crank design on the 2009 990 Adventure
ABS fitted on the standard model
Gel seat available as an optional extra on the R model
250km on/off road trek in Sardinia
Top-of-the-range on/off road machine in KTMs range
Most powerful yet with 115bhp from the Superduke-derived engine
Extra off-road capability with 55mm extra suspension travel
Firmer settings make it more composed on bumpy roads without compromising the ride quality
Limited by the standard tyres in wet mud
Power may be intimidating for novice riders
Versatile as the standard bike but with a little bit more ability everywhere
