The KTM 950 Supermoto R is a beast of a bike, with a 75-degree V-twin engine that unleashes a torrent of power and torque. Its 4-valve, DOHC configuration and 950cc displacement make it a force to be reckoned with on the road, as well as on the track.
The riding experience is visceral and intense, with a seat designed to provide a comfortable 40-mile ride, but then unleashing a high-speed chase that’s sure to get your adrenaline pumping. The Brembo front brakes and Pirelli Scorpion Sync tires work in tandem to stoppie-stopping with ease, giving you the confidence to push the limits of this incredible machine.
But be warned: this bike has a way of getting under your skin, and once you’ve ridden it, you’ll be hooked. With its unique blend of power, handling, and style, the KTM 950 Supermoto R is an experience unlike any other, and one that will leave you breathless and yearning for more.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
57.4 cubic inches / 942 cc
Max Power
98 hp / 72 kW @ 8500 rpm
Max Torque
70.1 ft-lb / 95 nm
Fuel Tank Capacity
15 Litres / 3.9 gal
Seat Height
34.45 inches / 875 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 950 Supermoto R
Year
2007 – 2008
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
57.4 cubic inches / 942 cc
Bore x Stroke
100 x 60 mm
Compression Ratio
11.5;1
Max Horsepower
98 hp / 72 kW @ 8500 rpm
Max Torque
70.1 ft-lb / 95 nm
Engine Management System
2X 43mm Keihin constant pressure
Lubrication System
Pressure lubrication with 2 Eaton pumps
Cooling System
Liquid cooling
Performance
Top Speed
137 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Tubular cromoly spaced frame. powered coated
Front Suspension
48mm WP Upside down adjustable
Front Suspension Travel
7.8 inches / 200 mm
Rear Suspension
WP shock, fully adjustable
Rear Suspension Travel
8.2 inches / 210 mm
Rake
24.4
Trail
109 mm / 4.3 in
Wheels & Brakes
Front Tire Size
120/70 -ZR17
Rear Tire Size
180/55 -ZR17
Front Brakes
2x 305mm discs 4 piston calipers
Rear Brakes
Single 240mm disc 1 piston caliper
Dimension & Weights
Seat Height
34.45 inches / 875 mm
Wheelbase
59.3 inches / 1505 mm
Ground Clearance
195 mm / 7.7 in
Fuel Tank Capacity
15 Litres / 3.9 gal
Dry Weight
191 kg / 421 lbs
Features
Four stroke, 75V-twin cylinder engine
DOHC, 4 valves per cylinder
40-mile seat designed for high-speed riding
Brembo front brakes
Pirelli Scorpion Sync tires
Point of balance allows for easy stoppie stopping
428 pounds dry weight
8 inches of travel front and rear from WP suspension
Dedicated streetbike with supermoto design features
Inspired by dirtbike experience and supermoto racebikes
In-command riding position
Minimal bodywork
Grippy tires
Light weight
Fuel tank designed to resemble sport-standard bikes
