The KTM 890 Adventure R Rally is the culmination of KTM’s expertise in rally raid racing, distilled into a highly specialized motorcycle that sets a new benchmark for Adventure riding. The 890cc parallel-twin engine is a marvel, delivering a thrilling rush of power and torque, its ultra-light Akrapovič silencer a nod to the brand’s racing heritage. At the heart of this machine lies a sophisticated suspension system, courtesy of WP Pro Components, which ensures a seamless blend of comfort and agility.
Whether carving through treacherous terrain or devouring endless miles of asphalt, the KTM 890 Adventure R Rally is an unyielding companion, its rally-proven components and settings a testament to the brand’s unwavering commitment to performance. With its top-shelf WP Pro suspension, ultra-light exhaust, and specially calibrated engine, this limited-edition machine is the ultimate tool for the most seasoned adventurers.
From its aggressive styling, replete with racing graphics and winglets, to its purpose-built ergonomics and suspension, the KTM 890 Adventure R Rally is a concentrated dose of KTM’s rally raid DNA, distilled into a single, awe-inspiring motorcycle that embodies the essence of unbridled adventure.
Key Specifications
Engine Type
Four stroke, parallel twin cylinder, DOHC, 4 valves percylinder
Engine Capacity
54.3 cubic inches / 889 cc
Max Power
78.3 kw / 105 hp
Max Torque
73.7 ft-lb / 100 nm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Weight (Wet/Kerb)
463 lbs / 210 kg
Seat Height
35.8 inches / 910 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 890 Adventure R Rally
Year
2021
Engine
Engine Type
Four stroke, parallel twin cylinder, DOHC, 4 valves percylinder
Displacement
54.3 cubic inches / 889 cc
Bore x Stroke
90.7 x 68.8 mm
Compression Ratio
13.5:1
Max Horsepower
78.3 kw / 105 hp
Max Torque
73.7 ft-lb / 100 nm
Engine Management System
DKK DellOrto with 46mm throttle body
Lubrication System
Pressure lubrication with 2 oil pumps
Cooling System
Liquid cooled with water/oil heat exchanger
Exhaust
Akrapovič exhaust
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
PASC antihopping clutch, mechanically operated
Gearbox
6 Speed with quickshifter
Final Drive
Chain 520 X-Ring
Electrical & Electronics System
Starter
Electric
ABS
Bosch 9.1 MP incl. Cornering-ABS and offroad mode, disengageable
Chassis & Suspension
Frame Type
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front Suspension
48mm Fully adjustable WP Xplor Pro 7548 inverted open-cartridge forks
Front Suspension Travel
10.6 inches / 270 mm
Rear Suspension
Linkage-free fully adjustable WP Xplor Pro 6746 PDS shock
Rear Suspension Travel
10.6 inches / 270 mm
Rake
26.2
Trail
63.8
Wheels & Brakes
Wheels
D.I.D DirtStar rims
Front Wheel/Rim Size
2.50 x 21
Front Tire Size
90/90 x 21 Continental Twinduro TKC 80
Rear Wheel/Rim Size
4.00 x 18
Rear Tire Size
150/70 x 18 Continental Twinduro TKC 80
Front Brakes
2x 320mm discs with 4-piston radially mounted calipers
Rear Brakes
Single 270mm disc
ABS
Bosch 9.1 MP incl. Cornering-ABS and offroad mode, disengageable
Dimension & Weights
Seat Height
35.8 inches / 910 mm
Wheelbase
60.2 inches / 1529 mm
Ground Clearance
305 mm / 12 in
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight
463 lbs / 210 kg
Features
Four-stroke, parallel twin cylinder engine
DOHC, 4 valves per cylinder
Chromium-Molybdenum-Steel frame
Engine as stressed element
Powder coated frame
48mm Fully adjustable WP Xplor Pro forks
Inverted open-cartridge forks
Linkage-free fully adjustable WP Xplor Pro shock
2x 320mm discs with 4-piston radially mounted calipers
Bosch 9.1 MP with Cornering-ABS and offroad mode
Disengageable Cornering-ABS
Quickshifter+
RALLY ride mode
Straight racing seat
Rally footpegs
Clear screen
Winglets
Racing graphics and colors
Carbon fiber tank protectors
Anodized wheel rims with tubes
Akrapovič silencer (35% lighter than standard)
Euro5-ready engine
New 4-stroke, twin, DOHC engine
Increased power output (105 hp)
Increased torque (100 Nm)
