KTM 790 Adventure (2020)

KTM 790 Adventure (2020)

The KTM 790 ADVENTURE is a high-performance motorcycle that embodies the perfect blend of adventure touring and off-road capability. Its lightweight and compact design, paired with the punchy 95hp (70kW) LC8c in-line twin engine, makes it an ideal choice for long-distance travel and exploring the great outdoors.

Whether you’re tackling rugged mountain trails or navigating endless desert landscapes, the KTM 790 ADVENTURE is built to handle it all. The engine’s smooth power delivery, thanks to two balancer shafts, ensures a comfortable riding experience, even on long days in the saddle.

Thanks to its advanced cooling technology and redesigned stainless-steel exhaust system, the KTM 790 ADVENTURE can handle the heat of the moment, maintaining its advanced power and performance even in the most extreme conditions.

With its exceptional capability, impressive engine performance, and reliable design, the KTM 790 ADVENTURE is the ultimate travel companion for anyone seeking a thrilling adventure on two wheels.

Key Specifications

Engine TypeFour stroke, parallel twin cylinder, DOHC, 4 valve percylinder
Engine Capacity48.7 cubic inches / 799 cc
Max Power94hp / 70 kW @
Max Torque65 ft-lb / 88 nm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Weight (Wet/Kerb)448 lbs / 203 kg
Seat Height850 / 830 mm; 33.5 / 32.7 in
KTM 790 Adventure (2020)

All Specifications

Make & Model

ModelKTM 790 Adventure
Year2020

Engine

Engine TypeFour stroke, parallel twin cylinder, DOHC, 4 valve percylinder
Displacement48.7 cubic inches / 799 cc
Bore x Stroke88 mm x 65.7 mm
Max Horsepower94hp / 70 kW @
Max Torque65 ft-lb / 88 nm
Engine Management SystemDKK DellOrto, 46 mm Throttle Body
Lubrication SystemPressure Lubrication with Two Oil Pumps
Cooling SystemLiquid cooled
ExhaustStainless steel primary and secondary silencer

Performance

Top Speedn/a

Transmission

ClutchPASC (Power Assisted Slipper Clutch), Mechanically Operated
Gearbox6 Speed
Final DriveChain

Electrical & Electronics System

StarterElectric, 12V 10Ah

Chassis & Suspension

Frame TypeCroMoly Tubular Steel, Engine as Stressed Member, Subframe: CroMoly Steel Trellis
Front SuspensionAPEX 43mm WP upside-down forks.
Front Suspension Travel7.9 inches / 200 mm
Rear SuspensionWP monoshock
Rear Suspension Travel7.9 inches / 200 mm
Trail25.9
HandlebarAluminum, Tapered, 26/22 mm

Wheels & Brakes

Front Wheel/Rim Size2.50 x 21,
Front Tire Size90/90-21
Rear Wheel/Rim Size4.50 x 18
Rear Tire Size150/70-18
Front Brakes2x 320mm discs. ABS
Rear BrakesSingle 260mm disc. ABS

Dimension & Weights

Seat Height850 / 830 mm; 33.5 / 32.7 in
Ground Clearance233 mm / 9.2 in
Fuel Tank Capacity5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight448 lbs / 203 kg
Dry Weight189 kg / 416.7 lbs

Features

  • Four-stroke, parallel twin cylinder engine
  • DOHC, 4 valve per cylinder
  • 95 hp (70 kW) output
  • 6-speed sequential gearbox
  • Two balancer shafts for smooth power delivery
  • Long service intervals of 15,000 km
  • Advanced cooling technology for hot conditions
  • Redesigned stainless-steel exhaust system
  • Mid-exhaust sound damper for centralization of mass
  • Maximum exhaust system ground clearance
  • Compact, durable tubular CroMo steel frame
  • Lightweight steel trellis subframe
  • Steering damper for stability
  • Heavy-duty spoked 21-inch front wheel
  • Heavy-duty spoked 18-inch rear wheel
  • Advanced electronics for modern riding experience
  • Ability to ride up to 400 km between fuel stops
  • Sporty handling on tarmac and off-road capability
