In the realm of hard Enduro, one name stands above the rest: KTM’s LC4. This storied engine has been the benchmark for decades, and the 690 Enduro R is its latest incarnation. With its four-stroke, single-cylinder design and SOHC configuration, the LC4 delivers unbeatable power and efficiency.
The 690 Enduro R is not just a machine, but a finely tuned instrument designed to conquer the toughest terrain. Its robust off-road technology and high-reliability engineering make it the perfect companion for riders seeking adventure.
Whether you’re carving through dense forests or tackling treacherous mountain passes, the 690 Enduro R’s perfect balance of power and ridability will leave you breathless. And when the pavement beckons, its solid street riding behaviour makes it a joy to ride on the road.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Engine Capacity
690 cc / 42.1 cu in
Max Power
63 hp / 46.kW@7500 rpm
Max Torque
65Nm / 47.9 ft-lb@6550 rpm
Fuel Tank Capacity
3.17 US gallons / 12.0 L
Weight (Wet/Kerb)
330 lbs / 150 kg
Seat Height
35.8 inches / 910 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 690 Enduro R
Year
2009 – 2010
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Displacement
690 cc / 42.1 cu in
Bore x Stroke
102×84.5mm
Compression Ratio
11.7:1
Max Horsepower
63 hp / 46.kW@7500 rpm
Max Torque
65Nm / 47.9 ft-lb@6550 rpm
Lubrication System
Pressure lubrication with 2 Eaton pumps
Cooling System
Liquid cooling system, continuous circulation with water pump
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
APTCAnti-hopping clutch in oil bath / hydraulically operated
Gearbox
6 Speed, claw shifted
Final Drive
Chain
Electrical & Electronics System
Starter
Electric, automatic decompressor
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
WP Suspension4860 D48/26 MA, 48 mm
Front Suspension Travel
10.8 inches / 275 mm
Rear Suspension
WP Suspension4618 withPro‑Leverlinkage
Rear Suspension Travel
10.8 inches / 275 mm
Trail
63
Wheels & Brakes
Front Tire Size
90/90 -21
Rear Tire Size
140/80 -18
Front Brakes
Single 300 mm Brembo disc brake with two-piston brake caliper, floating, ABS
Rear Brakes
Single240 mm Brembo disc brake with single-piston brake caliper, floating, ABS
Dimension & Weights
Seat Height
35.8 inches / 910 mm
Wheelbase
59.2 inches / 1504 mm
Ground Clearance
280 mm / 11.0 in
Fuel Tank Capacity
3.17 US gallons / 12.0 L
Wet (kerb/curb) Weight
330 lbs / 150 kg
Dry Weight
139 kg / 306 lbs
Features
Four stroke engine
Single cylinder engine
SOHC design
4 valves per cylinder
Hard Enduro capabilities
Low weight
Maximum performance
Robust off-road technology
High reliability
Unbeatable power
Improved ridability
Perfect technology
Off-road chassis
All-rounder capabilities
Phenomenal Enduro qualities
Solid street riding behavior
