The KTM 660 Rally is an unapologetic beast, engineered to dominate the rally raid events and leave all others in its dust. Its Austrian manufacturer has carefully crafted an unbeatable package, featuring a 48-liter fuel tank, factory-tuned suspension, steering damper, map scroller, and trip computers.
The engine’s pulling power is nothing short of astonishing, rivaling that of a Mack truck, yet weighing in at a mere 200 kilograms fueled. Its maneuverability and handling are exceptional, making it a comfortable and intuitive ride for even the most seasoned riders.
Whether on the toughest off-road terrain or the most treacherous rally course, the KTM 660 Rally is an outright class winner, setting the standard for all others to follow.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Engine Capacity
39.9 cubic inches / 653.7 cc
Max Power
48 kw / 65.2 hp
Max Torque
69 Nm / 7.04 kgf-m / 50.9 lb-ft @ 6000 rpm
Fuel Tank Capacity
55 L / 14.5 US gal / 12.1 Imp gal
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 660 Rally
Year
2003 – 2006
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Displacement
39.9 cubic inches / 653.7 cc
Bore x Stroke
102 80mm
Compression Ratio
11.5:1
Max Horsepower
48 kw / 65.2 hp
Max Torque
69 Nm / 7.04 kgf-m / 50.9 lb-ft @ 6000 rpm
Engine Management System
40 mm Carburetor
Cooling System
Liquid Cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multiple discs, cable operated
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & electric
Chassis & Suspension
Frame Type
Steel, single cradle frame
Front Suspension
50 mm WP upside-down fork
Front Suspension Travel
11.6 inches / 295 mm
Rear Suspension
WP monoshock, swinging arm
Rear Suspension Travel
12.5 inches / 320 mm
Rake
28
Trail
120 mm / 4.7 in
Wheels & Brakes
Front Tire Size
90/90 – 21
Rear Tire Size
140/90 – 18
Front Brakes
Single 320 mm disc
Rear Brakes
Single 220 mm disc
Dimension & Weights
Ground Clearance
320 mm / 12.5 in
Fuel Tank Capacity
55 L / 14.5 US gal / 12.1 Imp gal
Dry Weight
162 kg / 357 lbs
Features
660cc engine
48 litre fuel tank
Factory-tuned suspension
Steering damper
Map scroller
Trip computers
Low weight of around 200 kg
Exceptional manoeuvrability
Exceptional handling
Outright class winner in rally raid events
Limited production run of 45 units for 2006
Built for dominating rally raid events
MACK truck-like pulling power
