The KTM 625 SMC is a testament to the Austrian manufacturer’s commitment to building high-performance motorcycles that deliver on both on and off-road capabilities. Powered by a 625cc, four-stroke, single-cylinder engine, this bike boasts a robust SOHC design with four valves per cylinder, ensuring a potent and efficient power delivery. The engine’s characteristics are perfectly suited for the demands of both trail riding and spirited road work, with a strong mid-range and a willingness to rev that makes it a joy to ride.
The 625 SMC’s engine is an exercise in balance and finesse, offering a seamless blend of power and control that’s as at home on tight singletrack as it is on the twisties. With its compact dimensions and agile handling, this bike invites the rider to push its limits, exploring the boundaries of speed and agility with confidence.
Its potent engine and nimble handling make the KTM 625 SMC an ideal choice for riders seeking a versatile and thrilling motorcycle experience.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Engine Capacity
625 cc / 38.1 cu in
Max Power
41 kw / 55 hp
Max Torque
51Nm / 5.2 kgf-m / 38 lb-ft @ 3500 rpm
Fuel Tank Capacity
9.5 L/ 2.5 US gal / 2.1 Imp gal
Seat Height
35.8 inches / 910 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 625 SMC
Year
2004
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Displacement
625 cc / 38.1 cu in
Bore x Stroke
101 x 78 mm
Compression Ratio
11.5:1
Max Horsepower
41 kw / 55 hp
Max Torque
51Nm / 5.2 kgf-m / 38 lb-ft @ 3500 rpm
Engine Management System
Keihin FCR MX-41
Cooling System
Liquid cooled
Performance
Top Speed
180 km/h / 112 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & electric
Chassis & Suspension
Frame Type
Tubular steel cradle
Front Suspension
48 mm WP upside-down fork
Rear Suspension
WP monoshock
Trail
63 mm / 2.5 in
Wheels & Brakes
Front Tire Size
120/70 – 17
Rear Tire Size
160/50 – 17
Front Brakes
Single 320 mm disc, 4 piston caliper
Rear Brakes
Single 220mm disc, 1 piston caliper
Dimension & Weights
Seat Height
35.8 inches / 910 mm
Wheelbase
59.4 inches / 1510 mm
Ground Clearance
290 mm / 11.4 in
Fuel Tank Capacity
9.5 L/ 2.5 US gal / 2.1 Imp gal
Dry Weight
146 kg / 322 lbs
Features
Four stroke engine
Single cylinder
SOHC (Single Overhead Camshaft) design
4 valves per cylinder
