The KTM 620 RXC is a versatile, off-road focused motorcycle that showcases the Austrian manufacturer’s expertise in building hard-hitting, no-nonsense machines. Its 620cc single-cylinder engine is a real gem, producing a healthy 45 horsepower and 42 Nm of torque, making it suitable for both trail riding and more aggressive off-road excursions.
The RXC’s engine is characterized by its snappy throttle response and strong mid-range punch, making it an absolute blast to ride on technical trails and tight single-track sections. Its 6-speed transmission and robust clutch make it a pleasure to shift and control, allowing riders to focus on the ride rather than worrying about gear changes.
The KTM 620 RXC’s off-road prowess is further enhanced by its lightweight aluminum frame, long-travel suspension, and grippy Continental TKC 80 tires, making it an incredibly capable and forgiving off-road machine. With its impressive capabilities and user-friendly nature, the KTM 620 RXC is an excellent choice for both seasoned off-road enthusiasts and newcomers alike, and it’s sure to bring a huge grin to the faces of all who ride it.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Engine Capacity
609 cc / 37.2 cu in
Max Power
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Seat Height
37 inches / 940 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 620 RXC
Year
1998
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Displacement
609 cc / 37.2 cu in
Bore x Stroke
101 x 76 mm
Compression Ratio
10.4:1
Max Horsepower
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Engine Management System
Dell’Orto PHM 40 SD
Cooling System
Liquid cooled
Performance
Top Speed
155 km/h / 96 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & electric
Chassis & Suspension
Front Suspension
WP Telescopic forks, compression and rebound adjustable
Rear Suspension
Single chock, preload, compression and rebound adjustable
Wheels & Brakes
Front Tire Size
100/90 – 19
Rear Tire Size
140/80 – 17
Front Brakes
Single 320 mm disc, 4 piston caliper
Rear Brakes
Single 220 mm disc, 1 piston caliper
Dimension & Weights
Seat Height
37 inches / 940 mm
Dry Weight
139 kg / 306 lbs
