Get ready to experience the ultimate adventure on two wheels with KTM’s 620 LC4 Adventure. This versatile motorcycle seamlessly blends the agility of a dual-purpose bike with the ruggedness of a rally racer. The liquid-cooled, counterbalanced 608cc four-stroke engine delivers a thrilling ride, while the wide-ratio five-speed transmission ensures smooth power delivery.
The Adventure’s rally-inspired features, including a massive 7.4-gallon fuel tank and fairing, give it a commanding presence on the road. Heavier-duty WP suspension, including a massive 50mm conventional fork, provides exceptional handling and stability, making it the perfect companion for both on-road commutes and off-road adventures.
Whether you’re carving through twisties or tackling rough terrain, the KTM 620 LC4 Adventure’s unique blend of power, handling, and features will leave you craving more. Its ability to adapt to any riding style, coupled with its robust build and attention to detail, makes it the ultimate adventure bike for the modern rider.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Engine Capacity
609 cc / 37.2 cu in
Max Power
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Fuel Tank Capacity
28 L / 7.4 US gal / 6.2 Imp gal
Seat Height
37.2 inches / 945 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 620 LC4 Adventure
Year
1996
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Displacement
609 cc / 37.2 cu in
Bore x Stroke
101 x 76 mm
Compression Ratio
10.4:1
Max Horsepower
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Engine Management System
Dell’Orto PHM 40 SD
Cooling System
Liquid cooled
Performance
Top Speed
167 km/h / 104 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & electric
Chassis & Suspension
Front Suspension
50mm Telescopic forks, compression and rebound adjustable
Rear Suspension
Single chock, preload, compression and rebound adjustable
Wheels & Brakes
Front Tire Size
90/90 – 21
Rear Tire Size
130/80 – 18
Front Brakes
Single 320 mm disc, 4 piston caliper
Rear Brakes
Single 220 mm disc, 1 piston caliper
Dimension & Weights
Seat Height
37.2 inches / 945 mm
Fuel Tank Capacity
28 L / 7.4 US gal / 6.2 Imp gal
Dry Weight
146 kg / 322 lbs
Features
Liquid-cooled, counterbalanced, 608cc, four-valve Single engine
Dry-sump lubrication system with oil storage in the frame
Wide-ratio five-speed transmission
Electric starter with cam-mounted automatic decompression system
7.4-gallon fuel tank
Matching fairing
Roughcast engine finish with center cases identical to factory rally racers
Heavier-duty WP suspension
50mm conventional fork
Beefed-up rear subframe
11.8-inch front brake rotor
Dual-purpose cockpit with LCD tripmaster/odometer and analog rev-counter
QwikSilver 38mm flat-slide carb
SuperTrapp end caps for the 2-1-2 exhaust system
U.S. Forestry Service-approved exhaust system
37.2-inch-high seat
Ground Clearance for easy navigation on uneven terrain
Weight: 404 pounds (full tank), 384 pounds (dry)
Seating position is comfortable for both street and dirt riding
Smooth, linear power delivery
