The 1997 KTM 620 Duke is a menacing machine that lives for three things and three things only: wheelies, stoppies, and rorty romps through the gearbox.
This 609cc single-cylinder powerhouse is a direct descendant of the hybrid racebikes used in the early-’80s “Superbikers” shows, where it was run on a half-dirt, half-asphalt course. The result is a bike that thrives on raw power and agility, with a chassis based heavily on KTM’s off-road frame and a polished aluminum swingarm.
But be warned: the Duke is not for the faint of heart. It’s a bike that rewards its rider with a thrilling experience, but will also leave them breathless and grinning from ear to ear. So, if you’re ready to push the limits of what a street bike can do, the KTM 620 Duke is the ultimate adrenaline rush.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Engine Capacity
609 cc / 37.2 cu in
Max Power
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Fuel Tank Capacity
2.7 US gallons / 10.3 L
Seat Height
35.2 inches / 894 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 620 Duke
Year
1997
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Displacement
609 cc / 37.2 cu in
Bore x Stroke
101 x 76 mm
Compression Ratio
10.4:1
Max Horsepower
40.1 kw / 55 hp
Max Torque
60 Nm / 6.1 kgf-m / 44.3 lb-ft @ 5500 rpm
Engine Management System
Dell’Orto PHM 40 SD carburetor
Cooling System
Liquid cooled
Performance
Top Speed
169 km/h / 105 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Front Suspension
White Power 4054 Top Adjuster
Front Suspension Travel
5.6 inches / 142 mm
Rear Suspension
White Power monoshock 4681 BAVP Single Adjuster
Wheels & Brakes
Front Tire Size
120/70 – 17 Pirelli MT60
Rear Tire Size
160/60-17 Pirelli MT60
Front Brakes
Single 320 mm disc, 4 piston caliper
Rear Brakes
Single 220 mm disc, 1 piston caliper
Dimension & Weights
Seat Height
35.2 inches / 894 mm
Fuel Tank Capacity
2.7 US gallons / 10.3 L
Dry Weight
145 kg / 320 lbs
Features
609cc single-cylinder engine
40mm WP Roma fork
Brembo four-piston caliper
Polished aluminum swingarm
3-gallon fuel tank
Black plastic tank
Gray-on-black checkerboard pattern shrouds
Plastic shrouds with faux-carbon fiber finish
Dark metallic-gray paint on side panels and rear fender
Passenger grabrails
Subfender/chain-guard
Roadrace-quality Brembo brakes
Four-piston caliper capable of severe stoppage
Dutch-made WP Roma fork
Mated WP Roma fork and Brembo four-piston caliper
Similar roadracing front brakes to those used in early-’80s “Superbikers” shows
Shortened suspension
Big-bore two-stroke motocrossers with tlat-track tires
Hybrid racebike design
Direct descendant of early-’80s made-for-TV “Superbikers” shows
