The KTM 520 EXC is a game-changing, four-stroke motorcycle that defies convention with its impressive power and agility. Featuring a single cylinder, SOHC design with 4 valves per cylinder, this beast of an engine delivers a thrilling riding experience. Unlike its two-stroke counterpart, the 520 EXC is designed to provide a more relaxed and versatile ride, making it perfect for riders who crave a mix of speed and control.
The 520 EXC’s engine character is a true marvel, offering a wide power band that’s both tractable and explosive. Whether you’re carving through tight trails or cruising across open terrain, this motorcycle is always ready to adapt to your riding style.
But what truly sets the KTM 520 EXC apart is its ability to balance aggression and finesse. It’s a bike that can be ridden with a relaxed, smooth touch or unleashed with a more aggressive, high-performance approach – and it excels in both modes.
And so, after months of searching for the perfect four-stroke motorcycle, I finally found my match in the KTM 520 EXC – a bike that has forever changed the way I ride and experience the thrill of off-road adventure.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Engine Capacity
510.4 cc / 31.1 in
Fuel Tank Capacity
2.2 US gallons / 8.5 L
Seat Height
36.4 inches / 925 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 520 EXC
Year
2000 – 2002
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Displacement
510.4 cc / 31.1 in
Bore x Stroke
95 x 72 mm
Engine Management System
KeihinMX FCR 39
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric & kick
Chassis & Suspension
Front Suspension
43mm WP USD fork
Rear Suspension
Fully adjustable WP
Wheels & Brakes
Front Tire Size
90/90 – 21
Rear Tire Size
140/80 – 18
Front Brakes
Single 260 mm disc
Rear Brakes
Single 220 mm disc
Dimension & Weights
Seat Height
36.4 inches / 925 mm
Wheelbase
58.3 inches / 1481 mm
Fuel Tank Capacity
2.2 US gallons / 8.5 L
Dry Weight
112 kg / 247 lbs
Features
Four stroke, single cylinder engine
SOHC design
4 valves per cylinder
520cc displacement
248lbs dry weight
Electric start
Narrow-waisted design
Low center of gravity
Roomy ergonomics
Light and tractable power band
Suitable for relaxed or aggressive riding
Similar to a 250 in size and feel
Unique design compared to other motorcycles in its class
Suitable for trail riding and technical sections
