KTM 500 EXC-F Six Days (2022)

KTM 500 EXC-F Six Days (2022)

The KTM 500 EXC-F Six Days is a masterclass in refinement and attention to detail. Building on the already impressive 2022 KTM 500 EXC-F, this special edition model takes the dual-sport experience to new heights. With a robust skid plate protecting the engine and upgraded braking system featuring a solid rear disc and floating front disc, the Six Days is designed to tackle the toughest terrain with confidence.

But it’s not just about the hardware – the Six Days also boasts a slew of aesthetic upgrades, including an orange-painted frame, CNC-milled triple clamp, and eye-catching logos on the exhaust, rims, and handlebar. The bold graphics and distinctive color scheme scream exclusivity and performance.

Whether you’re a seasoned enduro enthusiast or just looking for a thrilling adventure machine, the KTM 500 EXC-F Six Days is the ultimate package – a symphony of power, style, and engineering that promises to leave you breathless and begging for more.

Key Specifications

Engine TypeFour stroke, single cylinder, SOHC, 4 valves per cylinder
Engine Capacity31.1 cubic inches / 510.4 cc
Fuel Tank Capacity2.25 US gallons / 8.5 L
Weight (Wet/Kerb)254 lbs / 115 kg
Seat Height37.8 inches / 960 mm
KTM 500 EXC-F Six Days (2022)

All Specifications

Make & Model

ModelKTM 500 EXC-F Six Days
Year2022

Engine

Engine TypeFour stroke, single cylinder, SOHC, 4 valves per cylinder
Displacement31.1 cubic inches / 510.4 cc
Bore x Stroke95 x 72 mm
Compression Ratio11.9:1
Engine Management SystemKeihin EFI with 42mm throttle body
Lubrication SystemPressure lubrication with 2 pumps
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchWet multi-disc DDS clutch with Brembo hydraulics
Gearbox6 Speed wide ratio
Primary Drive Ratio32:76
Gear Ratios1st 14:36 / 2nd 17:32 / 3rd 19:28 / 4th 22:26 / 5th 23:24 / 6th 26:21
Final DriveChain 5/8 x 1/4

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeCentral double-cradle type 25CrMo4
Front Suspension48mm Fully adjustable WP Xplor inverted fork
Front Suspension Travel11.8 inches / 300 mm
Rear SuspensionLinkage-free fully adjustable WP Xplor shock with PDS
Rear Suspension Travel12.2 inches / 310 mm
Rake26.5
Trail63.5

Wheels & Brakes

Front Wheel/Rim SizeGiant 1.60 – 21
Front Tire Size90/90 – 21
Rear Wheel/Rim SizeGiant 2.15 – 18
Rear Tire Size120/90 – 18
Front BrakesSingle 260 mm Galfer Wave disc with Brembo caliper
Rear BrakesSingle 220 mm Galfer Wave disc with Brembo caliper

Dimension & Weights

Seat Height37.8 inches / 960 mm
Wheelbase58.3 inches / 1480.8 mm
Ground Clearance355 mm / 13.9 in
Fuel Tank Capacity2.25 US gallons / 8.5 L
Wet (kerb/curb) Weight254 lbs / 115 kg

Features

  • Skid plate protects the engine
  • Upgraded braking system with solid rear disc
  • Floating front disc
  • Safety wire secures the brake pedal
  • Front axle puller for faster wheel changes
  • Orange-painted frame
  • Orange anodized CNC-milled triple clamp
  • Orange chain guide with black reinforcement
  • KTM Six Days logo on the exhaust
  • KTM Six Days logo on the rims
  • KTM Six Days logo on the handlebar
  • Bold Six Days Graphics
  • All updates from the 2022 500 EXC-F model applied to the Six Days
