The 2022 KTM 450 SMR is the ultimate Supermoto machine, razor sharp on asphalt and boasting newly-enhanced aesthetics that scream racing pedigree. With its championship-winning engine, the 450 SMR delivers a swift and powerful punch, segment-benchmarking handling and power that gets even closer to the KTM racing family.
The engine, tweaked for Supermoto use, packs a punch with its 59.5-pound weight and on-demand horsepower, while a Pankl Racing Systems 5-speed gearbox and 44mm Keihin throttle body provide instantaneous, confidence-inspiring throttle response.
Unrivalled handling is delivered by the precision-fabricated chromium molybdenum steel frame, perfect torsion, and flex characteristics, coupled with a 16mm offset geometry and three-way adjustable handlebar. WP XACT suspension, premium wheels, and Bridgestone racing slick tires complete the package, making the 2022 KTM 450 SMR the perfect machine for living on the limits of traction. With its array of premium parts, the 450 SMR is ready to dominate any Supermoto track or riding terrain.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valve
Engine Capacity
27.4 cubic inches / 449.9 cc
Max Power
63 hp
Fuel Tank Capacity
1.85 US gallons / 7.0 L
Seat Height
35 inches / 890 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 450 SMR
Year
2022
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valve
Displacement
27.4 cubic inches / 449.9 cc
Bore x Stroke
95x 63.4 mm
Compression Ratio
12.75:1
Max Horsepower
63 hp
Engine Management System
Keihin EFI with 44 mm throttle body
Lubrication System
Pressure lubrication with 2 rotor pumps
Cooling System
Liquid cooled
Exhaust
Aluminum
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Suter slipper clutch with Brembo hydraulics
Gearbox
5Speed
Primary Drive Ratio
31:76
Final Drive
Chain 5/8 x 1/4
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Central double-cradle-type 25CrMo4 steel
Front Suspension
48mm Fully adjustable WP Xact inverted fork
Front Suspension Travel
11.2 inches / 284.5 mm
Rear Suspension
Linkage-assisted WP Xact shock
Rear Suspension Travel
10.5 inches / 266.7 mm
Rake
26.1
Trail
63.9
Handlebar
Neken 28-22mm diameter w/ ODI grips
Wheels & Brakes
Wheels
Alpina
Front Tire Size
125/60 x 16.5, Bridgestone Battlax Supermoto
Rear Tire Size
165/65 x 17, Bridgestone Battlax Racing
Front Brakes
Single 310 mm disc with Brembo hydraulics
Rear Brakes
Single 220mm disc with Brembo hydraulics
Dimension & Weights
Seat Height
35 inches / 890 mm
Wheelbase
1468 mm 10 mm / 57.8 0.4 in
Ground Clearance
290 mm / 11.4 in
Fuel Tank Capacity
1.85 US gallons / 7.0 L
Dry Weight
102 kg / 224.8 lbs
Features
Ultra-light chromoly steel frame
New frame finishing coated in racing orange
Advanced four-stroke 450 cc powerplant
WP Suspension XACT AER 48 mm forks
WP Suspension XACT rear shock
PANKL Racing Systems 5-speed gearbox
SUTER anti-hopper clutch
Brembo 4-piston radial caliper
310 mm floating front disc
220 mm rear disc
Supermoto 16.5/17 ALPINA light wheels
Bridgestone racing slick tires
44 mm Keihin throttle body
Three-way adjustable handlebar
CNC-machined triple clamps
16 mm offset geometry
Premium Brembo master cylinder setup
